Rectangular green circuit board module with screw terminals and a small indicator light, approximately 12.5 by 6.6 by 3.3 centimetres

GCON

GCON AC-DC 12V 17A 204W Power Supply Module

SKU CH-RABB-MD1P9

Converts AC 100–265 V to stable DC 12 V at 17 A (204 W) with peak 20 A, built-in protection and indicator light

  • Industrial-grade double-sided PCB for stable reliable operation
  • Wide AC 100-265V 50/60Hz input suits global mains voltages
  • Rated 12V 17A 204W with peak 12V 20A 240W output
  • Over-voltage overload short-circuit protection trips above 22A
  • Compact 12.5104x6.5659x3.3cm module includes status indicator light

Industrial AC-DC module

This GCON power supply module converts AC input to a regulated DC 12 V output for industrial control systems and civil equipment. It delivers a continuous 17 A at 204 W and can peak at 20 A for short bursts. A built-in indicator light shows operating status at a glance.

Wide-range input and protection limits

The unit accepts AC 100 V to 265 V at 50 Hz or 60 Hz, making it suitable for varied mains environments worldwide. Over-voltage, overload and short-circuit protection engage automatically when output exceeds 22 A. Ripple and noise are specified at 200 mV on the DC rail.

Thermal headroom and capacity boundary

Continuous loads up to 180 W run with natural convection cooling alone. Sustained operation above 180 W up to the full 204 W rating requires forced-air cooling from an external fan. The module is not intended for applications that demand continuous output beyond its 17 A rating or peak currents above 20 A.

Highlights

  • Industrial-grade double-sided PCB for stable reliable operation
  • Wide AC 100-265V 50/60Hz input suits global mains voltages
  • Rated 12V 17A 204W with peak 12V 20A 240W output
  • Over-voltage overload short-circuit protection trips above 22A
  • Compact 12.5104x6.5659x3.3cm module includes status indicator light

Specifications

No published specifications for this item yet.

Questions about this item

How do I decide between running this module at its 17 A continuous rating versus the 20 A peak rating?

Run it at 17 A (204 W) for continuous operation; the 20 A (240 W) peak is only for short bursts. Above 180 W you must add a cooling fan, while below 180 W natural convection is sufficient.

What does the 204 W continuous rating actually deliver once the module is installed in my system?

You get a stable 12 V output (±0.5 V) at up to 17 A with 200 mV ripple. If the load tries to draw more than 22 A the module enters protection mode and shuts down.

What input-voltage range does the wide-range AC input support and what mains frequencies are accepted?

The module accepts 100–265 V AC at 50/60 Hz, so it works on most global mains supplies without any selector switch.
