Rectangular aluminium module with sealed gel coating and coloured wire leads

GCON

GCON 10V-36V to 12V 5A 60W Buck Boost Regulator IP67

SKU CH-21FG-T3H8A

Converts 10-36V input to stable 12V 5A output with 96% efficiency in an IP67-rated waterproof aluminium housing

  • High conversion efficiency up to 96% with synchronous rectification
  • Multiple protection circuits including over-heat and short-circuit safeguards
  • IP67 waterproof aluminium alloy housing with silica gel sealing
  • Colour-coded wiring for simple input and output connection
  • Compact buck-boost regulator powers devices from 10 V to 36 V input

10V-36V Input to 12V 5A Output

This DC-DC buck-boost regulator converts a wide 10V to 36V input range into a stable 12V output at up to 5A and 60W. It suits installers powering 12V accessories from variable vehicle or battery sources. The IP67-rated aluminium housing protects against dust and water ingress in exposed locations.

60W Capacity with 96% Peak Efficiency

Synchronous rectification delivers up to 96% conversion efficiency, keeping heat low during continuous loads. The unit handles motors, radios, navigation displays and similar 12V gear up to its 5A limit. Built-in over-temperature, short-circuit and transient voltage protection shut the output down before damage occurs.

IP67 Sealed Aluminium Housing

The potted aluminium alloy shell conducts heat away without any moving parts, allowing mounting in engine bays or outdoor enclosures. Colour-coded leads simplify wiring: red and black for input, yellow and black for output. It is not suited for loads exceeding 5A or for systems requiring galvanic isolation between source and load.

Highlights

  • High conversion efficiency up to 96% with synchronous rectification
  • Multiple protection circuits including over-heat and short-circuit safeguards
  • IP67 waterproof aluminium alloy housing with silica gel sealing
  • Colour-coded wiring for simple input and output connection
  • Compact buck-boost regulator powers devices from 10 V to 36 V input

Specifications

No published specifications for this item yet.

Questions about this item

Will the 10V-36V input range let me run this 12V 5A regulator from my existing vehicle system?

Yes, the regulator accepts any DC source between 10 and 36 volts and delivers a steady 12 volts at up to 5 amps.

How can I verify the unit is working correctly after wiring the red and black input leads and the yellow and black output leads?

Measure the output terminals with a multimeter; you should read 12 volts with the load connected and the converter will run cool thanks to 96% efficiency.

What comes in the box and do I need to buy any extra cables or connectors?

The converter itself is supplied in an IP67-rated aluminium shell with pigtail leads — red and black for input, yellow and black for output — so no separate wiring loom is required.
