Small matte-black metal desktop switch with eight RJ45 ports and two SFP slots on the front, fanless grille on the side

Fortinet

Fortinet FS-108F-POE network switch 8×RJ45 2×SFP PoE+ 65 W

SKU CH-C9M6-138J3 MPN FS-108F-POE

Managed desktop switch with eight PoE+ RJ45 ports, two SFP uplinks, and a 65 W power budget for converged voice, data, and wireless traffic

  • FormatDesktop
  • Network Management TypeManaged
  • Primary Ports8 x RJ45 + 2 x SFP
  • Management Interface8x GE RJ45 and 2x GE SFP
  • Management FeatureAutomation Stitches Display Average Bandwidth and Allow Sort
  • VLAN Support4K

Series 100F Series

Model FS-108F-POE

Show 1 more configurations
  • Fanless design enables silent operation in office spaces
  • 65 W PoE+ budget powers eight devices from one switch
  • FortiLink integration allows single-console management from FortiGate
  • 8× RJ45 and 2× SFP ports connect copper and fibre links
  • Desktop 44 × 209 × 250 mm form factor fits desks or racks

Desktop PoE+ switch for converged networks

The Fortinet FS-108F-POE is a managed Layer 2 switch with eight Gigabit RJ45 ports and two Gigabit SFP uplinks. All eight RJ45 ports support IEEE 802.3af/at PoE+ with a total power budget of 65 W. It is designed for desktop or wiring-closet installations that need voice, data and wireless traffic on a single fabric.

Fanless operation under sustained load

The unit runs without fans, relying on passive cooling to handle a maximum power draw of 74.4 W. Dynamically shared packet buffers and store-and-forward switching maintain wire-speed forwarding during continuous traffic. Dual firmware images and IPv4/IPv6 management features such as RFC 2697 and RFC 3168 support stable operation over long periods.

Compact metal chassis with flexible mounting

The enclosure measures 44 mm high, 209 mm deep and 250 mm wide, weighing 1.70 kg. Its desktop format suits tight spaces while the eight PoE+ ports and two SFP slots provide uplink flexibility. Management is available through FortiLink integration with a FortiGate, or via the onboard GUI, API and command line for non-FortiLink deployments.

Highlights

  • Fanless design enables silent operation in office spaces
  • 65 W PoE+ budget powers eight devices from one switch
  • FortiLink integration allows single-console management from FortiGate
  • 8× RJ45 and 2× SFP ports connect copper and fibre links
  • Desktop 44 × 209 × 250 mm form factor fits desks or racks

Specifications

BrandFortinet
Series100F Series
Model108F-POE
Part NumberFS-108F-POE
FormatDesktop
Network Management TypeManaged
Primary Ports8 x RJ45 + 2 x SFP
Management Interface8x GE RJ45 and 2x GE SFP
Management FeatureAutomation Stitches
Display Average Bandwidth and Allow Sorting on Physical Port / Interface Traffic
Dual Firmware Support
HTTP / HTTPS
IPv4 and IPv6 Management
Link Monitor
Managed from FortiGate
Packet Capture
POE Control Modes
Provide warning if L2 table is getting full
RMON Group 1
SNMP v1/v2c/v3
SNMP v3 traps
SNTP
Software download/upload: TFTP/FTP/GUI
SPAN, RSPAN, and ERSPAN
Standard CLI and Web GUI Interface
Support for HTTP REST APIs for Configuration and Monitoring
Syslog UDP/TCP
System alias command
System Temperature and Alert
Telnet / SSH
VLAN Support4K
IPv4 FeaturesRFC 2697: A Single Rate Three Color Marker
RFC 3168: The Addition of Explicit Congestion Notification (ECN) to IP
RFC 5227: IPv4 Address Conflict Detection
RFC 5517: Cisco Systems' Private VLANs: Scalable Security in a Multi-Client Environment
RFC 7039: Source Address Validation Improvement (SAVI) Framework
PoEYes
QoSEgress priority tagging
Explicit Congestion Notification
IEEE 1588 PTP (Transparent Clock)
IEEE 802.1p Based Priority Queuing
IP TOS/DSCP Based Priority Queuing
Percentage Rate Control
Layer 2 FeaturesAuto-negotiation for Port Speed and Duplex
Auto topology
Dynamically shared packet buffers
Edge Port / Port Fast
IEEE 802.1ad QinQ
IEEE 802.1AX Link Aggregation
IEEE 802.1D MAC Bridging/STP
IEEE 802.1Q VLAN Tagging
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3ad Link Aggregation with LACP
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.3ba, 802.3bj, and 802.3bm 40 and 100 Gigabit Ethernet
IEEE 802.3bz Multi Gigabit Ethernet
IEEE 802.3 CSMA/CD Ac
Layer 3 FeaturesBidirectional Forwarding Detection (BFD)
DHCP Relay
DHCP server
Dynamic Routing Protocols: OSPFv2, RIPv2, VRRP, ISIS *
Filtering routemaps based on routing protocol
IP conflict detection and notification
IPv6 route filtering
Static Routing (Hardware-based)
Unicast Reverse Path Forwarding - uRPF
PoE Ports8 (802.3af/at)
PoE Power Budget65 W
Max Power Consumption74.4 W
DimensionsHeight x Depth x Width (inches) 1.73 x 8.23 x 9.85
Height x Depth x Width (mm) 44 x 209 x 250
Weight3.75 lbs (1.70 kg)
FeaturesHardware Specifications
Dedicated Management 10/100 Port: 0
RJ-45 Serial Console Port: 1
Mean Time Between Failures: > 10 years
System Specifications
Switching Capacity (Duplex): 20 Gbps
Packets Per Second (Duplex): 30 Mpps
MAC Address Storage: 8 K
Network Latency: 4 µs
VLANs Supported: 4 K
Link Aggregation Group Size: 8
Total Link Aggregation Groups: 8
Packet Buffers: 512 KB
Memory: 256 MB DDR3
Flash: 32 MB
ACL: 640
Spanning Tree Instances: 32
Shipping weight2.72 kg
Package size1041 × 508 × 305 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much heat does the fanless FS-108F-POE generate when running at its 74.4 W maximum power consumption all day?

The fanless design dissipates heat silently; at the 74.4 W maximum draw the unit warms to a safe operating temperature without audible noise.

Which SFP transceivers must I already own to use the two GE SFP uplinks on this switch?

Any standard 1 GbE SFP module — single-mode or multi-mode — fits the two GE SFP ports for fibre uplinks.

Will the 65 W PoE+ budget power my older 802.3af phones and 802.3at access points simultaneously on the eight RJ45 ports?

Yes, the 65 W budget is shared across all eight PoE+ ports, so legacy 802.3af devices and newer 802.3at gear can run together within that limit.
