Compact desktop network switch in matte silver metal housing with eight RJ45 ports and two SFP slots on the front face

Fortinet

Fortinet FS-108F-FPOE 8-port PoE+ network switch

SKU CH-MPZP-ZZ46M MPN FS-108F-FPOE

An 8-port managed PoE+ switch with 130 W budget, two SFP uplinks and fanless desktop design for quiet converged networks

  • FormatDesktop
  • Network Management TypeManaged
  • Primary Ports8x GE RJ45 and 2x GE SFP
  • Management FeatureAutomation Stitches Display Average Bandwidth and Allow Sort
  • VLAN SupportYes
  • IPv4 FeaturesRFC 2697: A Single Rate Three Color Marker RFC 3168: The Add

Series 100F Series

Model FS-108F-FPOE

Show 1 more configurations
  • Managed from a single FortiGate console via FortiLink
  • 8 PoE+ ports deliver up to 130 W for phones and cameras
  • Fanless 44 mm height fits desktop or rack
  • Layer 2 and Layer 3 features include VLAN, STP, OSPFv2, RIPv2
  • Dual firmware and IPv4/IPv6 management simplify updates

FortiSwitch 108F-FPOE desktop switch

The FortiSwitch 108F-FPOE is a managed Layer 2 switch with eight Gigabit RJ45 ports and two Gigabit SFP uplinks. It is built for small offices or branch sites that need PoE+ power and centralized control from a FortiGate firewall. The fanless desktop chassis runs silently on a desk or in a wiring closet.

130 W PoE+ budget under continuous load

All eight ports deliver IEEE 802.3af/at power simultaneously up to a 130 W total budget. The switch draws a maximum of 139.2 W from its 100–240 V AC supply, so the power source must sustain that draw without interruption. Fanless convection cooling handles the thermal load in typical indoor ambient temperatures.

Two SFP uplinks limit aggregation bandwidth

The two 1 GbE SFP ports provide the only uplink path, capping total upstream throughput at 2 GbE even when all eight RJ45 ports run at wire speed. Link aggregation can combine the pair for redundancy or 2 GbE throughput, but no higher-speed uplink option exists on this model. Builders needing 10 GbE uplinks or more than two fibre links must choose a different switch.

Highlights

  • Managed from a single FortiGate console via FortiLink
  • 8 PoE+ ports deliver up to 130 W for phones and cameras
  • Fanless 44 mm height fits desktop or rack
  • Layer 2 and Layer 3 features include VLAN, STP, OSPFv2, RIPv2
  • Dual firmware and IPv4/IPv6 management simplify updates

Specifications

BrandFortinet
Series100F Series
Model108F-FPOE
Part NumberFS-108F-FPOE
FormatDesktop
Network Management TypeManaged
Primary Ports8x GE RJ45 and 2x GE SFP
Management FeatureAutomation Stitches
Display Average Bandwidth and Allow Sorting on Physical Port / Interface Traffic
Dual Firmware Support
HTTP / HTTPS
IPv4 and IPv6 Management
Link Monitor
Managed from FortiGate
Packet Capture
POE Control Modes
Provide warning if L2 table is getting full
RMON Group 1
SNMP v1/v2c/v3
SNMP v3 traps
SNTP
Software download/upload: TFTP/FTP/GUI
SPAN, RSPAN, and ERSPAN
Standard CLI and Web GUI Interface
Support for HTTP REST APIs for Configuration and Monitoring
Syslog UDP/TCP
System alias command
System Temperature and Alert
Telnet / SSH
VLAN SupportYes
IPv4 FeaturesRFC 2697: A Single Rate Three Color Marker
RFC 3168: The Addition of Explicit Congestion Notification (ECN) to IP
RFC 5227: IPv4 Address Conflict Detection
RFC 5517: Cisco Systems' Private VLANs: Scalable Security in a Multi-Client Environment
RFC 7039: Source Address Validation Improvement (SAVI) Framework
PoEYes
QoSEgress priority tagging
Explicit Congestion Notification
IEEE 1588 PTP (Transparent Clock)
IEEE 802.1p Based Priority Queuing
IP TOS/DSCP Based Priority Queuing
Percentage Rate Control
Layer 2 FeaturesAuto-negotiation for Port Speed and Duplex
Auto topology
Dynamically shared packet buffers
Edge Port / Port Fast
IEEE 802.1ad QinQ
IEEE 802.1AX Link Aggregation
IEEE 802.1D MAC Bridging/STP
IEEE 802.1Q VLAN Tagging
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3ad Link Aggregation with LACP
IEEE 802.3ae 10 Gigabit Ethernet
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.3ba, 802.3bj, and 802.3bm 40 and 100 Gigabit Ethernet
IEEE 802.3bz Multi Gigabit Ethernet
IEEE 802.3 CSMA/CD Ac
Layer 3 FeaturesBidirectional Forwarding Detection (BFD)
DHCP Relay
DHCP server
Dynamic Routing Protocols: OSPFv2, RIPv2, VRRP, ISIS *
Filtering routemaps based on routing protocol
IP conflict detection and notification
IPv6 route filtering
Static Routing (Hardware-based)
Unicast Reverse Path Forwarding - uRPF
PoE Ports8 (802.3af/at)
PoE Power Budget130 W
Power100–240V AC, 50/60 Hz
Max Power Consumption139.2 W
DimensionsHeight x Depth x Width (inches) 1.73 x 8.23 x 9.85
Height x Depth x Width (mm) 44 x 209 x 250
Weight4.05 lbs (1.84 kg)
FeaturesHardware Specifications
Dedicated Management 10/100 Port: 0
RJ-45 Serial Console Port: 1
Mean Time Between Failures: > 10 years
System Specifications
Switching Capacity (Duplex): 20 Gbps
Packets Per Second (Duplex): 30 Mpps
MAC Address Storage: 8 K
Network Latency: 4 µs
VLANs Supported: 4 K
Link Aggregation Group Size: 8
Total Link Aggregation Groups: 8
Packet Buffers: 512 KB
Memory: 256 MB DDR3
Flash: 32 MB
ACL: 640
Spanning Tree Instances: 32
Shipping weight1.81 kg
Package size1016 × 508 × 178 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much heat does the fanless 130 W PoE budget generate when the switch runs continuously?

The fanless design dissipates up to 139.2 W maximum power consumption silently, so heat output equals that draw without any fan noise.

What must I already own to manage the 8 PoE+ ports and 2 SFP uplinks through FortiLink?

A FortiGate firewall running FortiOS is required for FortiLink management; alternatively the onboard GUI, API or CLI can configure the switch standalone.

Will the 108F-FPOE interoperate with my existing IEEE 802.1Q VLAN trunk and 802.3af access points?

Yes, it supports IEEE 802.1Q tagging, 802.3af/at PoE on all eight RJ45 ports, and standard link aggregation for legacy trunk connections.
