Compact white desktop firewall appliance with four RJ45 ports and front status LEDs

Fortinet

Fortinet FortiGate 30G FG-30G-BDL-809-36 firewall appliance

SKU CH-KKQH-131M0 MPN FG-30G-BDL-809-36

Desktop firewall with four Gigabit Ethernet ports, 500 Mbps threat-protection throughput and three-year FortiCare Premium plus FortiGuard Enterprise Protection included

  • Form FactorDesktop
  • VPNSYSTEM PERFORMANCE - ENTERPRISE TRAFFIC MIX IPS Throughput:
  • ComplianceFCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA
  • Power InputPower Rating: 12VDC, 2A Power Source Powered by external DC
  • Max Power Consumption8.2 W
  • DimensionsHeight x Width x Length (inches): 1.6 x 5.6 x 6.3

Option w/ FortiCare Premium and FortiGuard Enterprise Protection (3-Y)

  • Enterprise-grade threat protection at 500 Mbps throughput
  • NGFW performance of 570 Mbps for secure application control
  • IPS inspection up to 800 Mbps keeps traffic flowing
  • 3-year FortiCare Premium and FortiGuard Enterprise Protection included
  • Desktop form factor draws only 8.2 W maximum power

Secure desktop appliance for distributed sites

The FortiGate 30G integrates next-generation firewall, SD-WAN and security services in a single desktop unit, targeting branch offices and small enterprises that need consolidated protection without rack infrastructure. It ships with a three-year FortiCare Premium and FortiGuard Enterprise Protection bundle for continuous updates and AI-driven threat intelligence.

Threat Protection Throughput at 500 Mbps

This figure represents the sustained inspection rate with IPS, application control and malware protection active, and it determines whether the appliance can handle your peak encrypted traffic without becoming a bottleneck. If your WAN link regularly exceeds 500 Mbps of inspected throughput, a higher-capacity model is required.

Passive cooling at 8.2 W maximum draw

The unit consumes no more than 8.2 W from its external 12 V DC adapter, which accepts 100-240 V AC at 50/60 Hz and draws 0.11 A at 100 V or 0.055 A at 240 V. With no moving parts, the desktop chassis operates silently in office environments while meeting FCC, CE, UL/cUL, CB, VCCI, BSMI, RCM and UKCA compliance.

Highlights

  • Enterprise-grade threat protection at 500 Mbps throughput
  • NGFW performance of 570 Mbps for secure application control
  • IPS inspection up to 800 Mbps keeps traffic flowing
  • 3-year FortiCare Premium and FortiGuard Enterprise Protection included
  • Desktop form factor draws only 8.2 W maximum power

Specifications

BrandFortinet
SeriesFortiGate 30G Series
ModelFortiGate 30G w/ 3-Y FortiCare Premium and FortiGuard Enterprise Protection
Part NumberFG-30G-BDL-809-36
Form FactorDesktop
VPNSYSTEM PERFORMANCE - ENTERPRISE TRAFFIC MIX
IPS Throughput: 800 Mbps
NGFW Throughput: 570 Mbps
Threat Protection Throughput: 500 Mbps
SYSTEM PERFORMANCE
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP):
4/ 4/ 3.9 Gbps
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP):
4/ 4/ 3.9 Gbps
Firewall Latency (64 byte UDP packets):
2.87 µs
Firewall Throughput (Packets Per Second):
5.85 Mpps
Concurrent Sessions (TCP):
600 000
New Sessions/Second (TCP):
30 000
Firewall Policies:
2000
IPsec VPN Throughput (512 byte):
3.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels:
200
Client-to-Gateway IPse
ComplianceFCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA
Power InputPower Rating:
12VDC, 2A
Power Source Powered by external DC power adapter:
100-240V AC, 50/60 Hz
Maximum Current:
100V/0.11A, 240V/0.055A
Max Power Consumption8.2 W
DimensionsHeight x Width x Length (inches): 1.6 x 5.6 x 6.3
Weight1.3 lbs (0.6 kg)
Shipping weight3.63 kg
Package size762 × 457 × 203 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 500 Mbps threat protection throughput mean for my branch office traffic?

It is the maximum sustained rate the appliance can inspect traffic with all security profiles enabled, so a 500 Mbps internet link would be the practical ceiling for fully protected throughput.

What do the four RJ45 ports support and what is their speed limit?

They are four Gigabit Ethernet ports, each capped at 1 Gbps, providing LAN, WAN and DMZ connectivity without any faster multi-gig option on this model.

What space and power does the desktop unit need on a shelf or desk?

It measures 1.6 by 5.6 by 6.3 inches, weighs 1.3 lbs, and draws up to 8.2 W from the included 12 V 2 A external adapter.
