Square aluminium frame axial fan with steel blades and terminal block, 225mm, 80mm deep

Fans

Fans W2E200-HH38-07 230V 80W 225mm case fan

SKU CH-XNS4-95XT8

AC axial fan delivers 607 CFM airflow at 61 dB(A) with die-cast aluminium housing and terminal block connection

  • High airflow of 607.0 CFM for effective cabinet cooling
  • 230 V AC rated voltage suits industrial power supplies
  • Ball bearing ensures long operating life with low maintenance
  • Die-cast aluminium frame provides rugged construction and IP20 protection
  • Motor stall protection adds safety during overload conditions

High-Airflow AC Axial Fan

The Fans W2E200-HH38-07 is a 230 VAC tubeaxial unit built for Rittal cabinet and industrial enclosure cooling. It delivers 607.0 CFM through a 225 mm square aluminum frame using steel blades and a ball bearing motor.

Sustained Operation With Motor Protection

Rated at 80 W, the fan runs continuously at 50 Hz or 60 Hz without thermal throttling thanks to integrated stall protection. The design maintains 17.00 m³/min airflow at 61.0 dB(A) under constant load in demanding environments.

Terminal Block Mounting In Metal Enclosures

Installation uses a terminal block connection suited for fixed wiring inside cabinets; no plug-and-play connector is supplied. The 80 mm depth and 4.4 lb weight require secure fastening to the 225 mm cutout to prevent vibration noise.

Highlights

  • High airflow of 607.0 CFM for effective cabinet cooling
  • 230 V AC rated voltage suits industrial power supplies
  • Ball bearing ensures long operating life with low maintenance
  • Die-cast aluminium frame provides rugged construction and IP20 protection
  • Motor stall protection adds safety during overload conditions

Specifications

No published specifications for this item yet.

Questions about this item

How loud is the 230 V 80 W fan at 61.0 dB(A) when running continuously?

The axial fan produces 61.0 dB(A) at full speed, a level comparable to a normal conversation, so it remains noticeable but not intrusive during all-day operation.

What power connection does the terminal block require for the 230 VAC supply?

The fan terminates in a terminal block designed for direct 230 VAC mains wiring; no additional adapter or low-voltage converter is needed.

Will the 225 mm square aluminum frame fit the mounting holes on my existing Rittal cabinet?

The 225 mm square frame matches standard Rittal cabinet cut-outs, and the aluminum housing aligns with the typical four-corner fixing pattern used on those enclosures.
