Fans W2E200-HH38-01 230V 80W 200mm Axial Case Fan

SKU CH-A5ER-PKNT7

230 VAC axial fan delivers 607.0 CFM airflow at 61.0 dB(A) with ball bearings and terminal block connection

  • High airflow of 607.0 CFM cools large enclosures effectively
  • Ball bearing design extends operating life in continuous use
  • 230 VAC supply suits industrial mains without extra transformers
  • Aluminium frame and steel blades resist vibration and corrosion
  • Certified to CCC, CE, CSA, EAC, UL and VDE standards

200 mm 230 V AC axial fan

This 200 mm tubeaxial fan runs on 230 VAC and draws 80 W, delivering 607.0 CFM at 61.0 dB(A). Ball bearings support continuous operation in industrial cabinets and inverter enclosures. The aluminium frame and steel blades meet CCC, CE, CSA, EAC, UL and VDE approvals.

Replaces worn OEM cabinet fans

It serves as a direct drop-in for failed ebm-papst W2E200 series units in ABB drives, HVAC plant and power-generation gear. The jump is worthwhile when the original fan exceeds its rated life or when noise and vibration rise above 61.0 dB(A).

Fits 225 mm square panel cut-outs

Terminal-block wiring simplifies installation in 225 mm x 225 mm openings with 80 mm depth. The 4.4 lb aluminium frame frees up internal volume compared with larger centrifugal blowers while maintaining 17.00 m³/min airflow.

Highlights

  • High airflow of 607.0 CFM cools large enclosures effectively
  • Ball bearing design extends operating life in continuous use
  • 230 VAC supply suits industrial mains without extra transformers
  • Aluminium frame and steel blades resist vibration and corrosion
  • Certified to CCC, CE, CSA, EAC, UL and VDE standards

Specifications

No published specifications for this item yet.

Questions about this item

What square cut-out and depth does the 225 mm frame with 80 mm width need to fit?

The aluminium frame is 225 mm square and 80 mm deep, so allow that cut-out plus clearance for the terminal block on the rear.

How do I wire the 230 VAC supply to the terminal block without reversing line and neutral?

Connect live and neutral to the two marked terminals on the block; the fan is not polarity-sensitive but follow local wiring codes and secure the cable gland.

When should the ball-bearing motor be inspected or replaced in continuous 80 W operation?

Ball bearings are sealed; schedule a visual and audible inspection at regular service intervals and replace the fan if noise exceeds the rated 61.0 dB(A) or vibration appears.
