Square black metal frame with all-metal blades, 172 by 150 by 55 mm

Fans

Fans THA1X-7556X-TP case fan 230V 172x150x55mm 211 CFM

SKU CH-514B-EKEJC MPN THA1X-7556X-TP

A 230 V AC axial fan measuring 172 by 150 by 55 mm delivers 211 CFM airflow with double ball bearings for 80,000 hours life

  • Air Flow15-20 CFM
  • High airflow of 211 CFM for effective cooling
  • 230 VAC operation suits industrial power supplies
  • All-metal blades and aluminium frame resist corrosion
  • Double ball bearing rated for 80,000 hours at 25 °C
  • Wide temperature range from -40 °C to +75 °C

Industrial 230 VAC cooling fan

The IKURA THA1X-7556X-TP is a new 172×150×55 mm axial fan built for 230 VAC industrial supplies. Its all-metal blade and die-cast aluminium frame suit medical, rail, EV and industrial equipment that require continuous airflow in harsh environments. High-precision double ball bearings support an 80,000-hour service life at 25 °C ambient. The unit operates from −40 °C to +75 °C.

Thermals noise and power draw

Rated power is 43 W at 50 Hz and 40 W at 60 Hz while the motor spins at 2,650 min⁻¹. Air volume reaches 211 CFM (360 m³/h) in the anticlockwise blade direction. Insulation resistance exceeds 500 MΩ and the fan withstands a 500 V, 0.5 A dielectric test for one minute. Supply tolerance is ±15 % of rated voltage.

Build integration requirements

The 172×150 mm footprint with 55 mm depth fits standard industrial cut-outs and the aluminium frame resists corrosion. No external driver is needed; the shaded-pole motor connects directly to 230 VAC mains within the stated tolerance. Storage temperature range spans −50 °C to +90 °C. Buyers needing variable-speed EC control or lower-voltage DC operation should select a different model.

Highlights

  • High airflow of 211 CFM for effective cooling
  • 230 VAC operation suits industrial power supplies
  • All-metal blades and aluminium frame resist corrosion
  • Double ball bearing rated for 80,000 hours at 25 °C
  • Wide temperature range from -40 °C to +75 °C

Specifications

Air Flow15-20 CFM

Questions about this item

How do I install the THA1X-7556X-TP fan and which step is often missed?

Mount the 172x150x55mm aluminium frame using its four corner holes, connect the 230VAC supply within the ±15% tolerance, and ensure the blades spin anticlockwise when viewed from the blade side — reversing the polarity will run the fan backwards.

What maintenance or replacement will the THA1X-7556X-TP need over its life?

The high-precision NIB double ball bearings are rated for 80,000 hours at 25°C; after that interval the bearing grease degrades and the fan should be replaced rather than re-lubricated.

What limit appears first when the THA1X-7556X-TP runs continuously at full load?

The 75°C operating-temperature ceiling is reached before the 500V insulation or 500MΩ resistance limits, so sustained use in hot enclosures will trigger thermal shutdown first.
