Rittal cabinet fan SK3241.100, matte metal housing, axial blades visible

Fans

Fans SK3241.100 Rittal cabinet case fan

SKU CH-50V0-MBC5V

A 230 V AC centrifugal fan rated at 40–45 W and 2,650–2,700 rpm for Rittal cabinet cooling from -30 °C to 55 °C

  • Operates reliably from -30 °C to 55 °C ambient
  • CE and UL 2111 approvals confirm safety compliance
  • 230 V AC supply suits industrial cabinet installations
  • Runs at 2650 rpm on 50 Hz or 2700 rpm on 60 Hz
  • Draws only 0.26 A at 50 Hz for 40 W power use

Rittal cabinet fan SK3241.100

This 230 VAC centrifugal fan is built for Rittal enclosures and industrial cabinets that need forced airflow in tight spaces. It suits integrators maintaining medical, rail, industrial cleaning or new-energy vehicle equipment where a direct OEM replacement is required.

Thermals and power at 50 and 60 Hz

At 50 Hz the motor draws 0.26 A and 40 W while spinning at 2650 rpm; at 60 Hz it draws 0.24–0.25 A, 42–45 W and reaches 2700 rpm. The unit is rated for continuous operation from -30 °C to 55 °C and carries CE and UL 2111 approvals.

Included hardware and documentation

The package supplies only the fan unit itself; no mounting brackets, filters, speed controllers or configuration software are bundled. Installers must reuse existing hardware or source compatible fixings separately.

Highlights

  • Operates reliably from -30 °C to 55 °C ambient
  • CE and UL 2111 approvals confirm safety compliance
  • 230 V AC supply suits industrial cabinet installations
  • Runs at 2650 rpm on 50 Hz or 2700 rpm on 60 Hz
  • Draws only 0.26 A at 50 Hz for 40 W power use

Specifications

No published specifications for this item yet.

Questions about this item

How do I wire the SK3241.100 fan to a 230 VAC supply and what is the common mistake?

Connect the single-phase motor to 230 VAC at 50 Hz or 60 Hz; the step often missed is confirming the local mains frequency matches the 50 Hz or 60 Hz rating on the label.

Which part of the SK3241.100 will need replacement first and how can I tell?

The motor bearings are the wear item; rising current draw above the rated 0.26 A at 50 Hz or 0.24 A at 60 Hz, or unusual noise, signals bearing fatigue.

What thermal limit stops the SK3241.100 from running continuously under load?

The maximum ambient temperature is 55 °C; sustained operation above this trips the motor’s thermal protection and halts the fan.
