Black aluminium frame 92x92x25mm AC fan with PBT blades and 25cm leads

Fans

Fans 9225 92x92x25mm 220-240V AC case fan

SKU CH-23QF-P8GPE MPN 9225

A 92 mm square AC case fan with ball-bearing motor running at 2250-2700 RPM, delivering 0.89-1.05 m³/min airflow at 33-37 dB-A

  • 92x92x25 mm frame fits standard 92 mm mounts
  • 220-240 V AC supply powers directly from mains without adapter
  • Ball bearing rated for long life and low noise operation
  • 89-1.05 m³/min airflow at 2250-2700 rpm for effective cooling
  • 33-37 dB-A acoustic output keeps system noise low

Purpose and fit

This 92 mm square AC fan suits industrial enclosures, server racks or legacy chassis that run from mains voltage. It is built for installers who need a direct 220–240 V connection without a separate power supply.

Decisive spec

The unit operates at 220–240 V AC, 50/60 Hz and draws 11/13 W while delivering 0.89/1.05 m³/min airflow at 2250–2700 R/min. Ball bearings and Class B insulation rated to 120 °C support continuous duty.

Build context

A 25 cm lead exits the die-cast aluminium frame for direct wiring into terminal blocks or IEC connectors. The PBT glass-reinforced blades meet VO flame-retardant standards. No PWM or speed-control header is present, so voltage regulation must be handled externally.

Highlights

  • 92x92x25 mm frame fits standard 92 mm mounts
  • 220-240 V AC supply powers directly from mains without adapter
  • Ball bearing rated for long life and low noise operation
  • 89-1.05 m³/min airflow at 2250-2700 rpm for effective cooling
  • 33-37 dB-A acoustic output keeps system noise low

Specifications

No published specifications for this item yet.

Questions about this item

What does the 1.05 M3/min airflow mean when the fan is running in a PC case?

It moves just over one cubic metre of air each minute at the higher speed, which is typical for a 92 mm fan in a compact chassis.

What does the 220-240 V AC rating cap in practice?

The fan connects directly to mains voltage, so it is limited to standard 220-240 V household supply and cannot be powered from a PC motherboard header.

Will the 92x92x25 mm frame with 25 cm leads fit my case fan mount?

It needs a standard 92 mm square mounting hole pattern and 25 mm clearance; the 25 cm flying leads reach most nearby terminal blocks or switches.
