Long silver cross-flow fan, 740 mm cylindrical rotor, metal housing, axial wire leads

Fans

Fans 740MM cross flow fan UF9060CBP23HL case fan

SKU CH-GSD4-JT4HZ

A 740 mm cross-flow case fan delivering up to 550 CFM at 55 dB for 120 V or 230 V systems

  • 740 mm cross-flow design moves 15.5 m³/min of air for high-volume cooling
  • Runs at 55 dB while delivering 550 CFM for quiet high-throughput operation
  • 120 V or 230 V input at 50/60 Hz fits global power without extra converters
  • 9 mmH₂O static pressure pushes air through dense filters and tight chassis paths
  • 2 150 RPM motor sustains airflow with 1.4 A locked-rotor protection for reliability

Product identity

This 740MM cross flow fan model UF9060CBP23HL delivers 550 CFM maximum airflow at 55 dB noise. It operates on 230 V supply at 50/60 Hz with 130-160 W input power. The unit weighs 6 kg and suits industrial cooling applications including medical equipment, rail vehicles, drive systems and hotel installations.

Voltage configuration

Two voltage variants exist: a 120 V version drawing 1.00-1.25 A rated current and a 230 V version drawing 0.55-0.70 A. Both share identical 2150/2100 RPM speeds, 15.5/15.0 m3/min airflow and 9/11 mmH2O pressure ratings. Lock current differs at 1.40 A versus 0.75 A respectively. Select the variant matching your mains supply.

Installation checks

Verify available mounting space for a 6 kg cross flow unit and confirm 230 V 50/60 Hz power compatibility. The 55 dB operating noise may exceed limits for quiet office or residential environments. Ensure ducting or chassis design accommodates cross flow air pattern rather than axial flow. No bundled accessories or software are included with this bare fan unit.

Highlights

  • 740 mm cross-flow design moves 15.5 m³/min of air for high-volume cooling
  • Runs at 55 dB while delivering 550 CFM for quiet high-throughput operation
  • 120 V or 230 V input at 50/60 Hz fits global power without extra converters
  • 9 mmH₂O static pressure pushes air through dense filters and tight chassis paths
  • 2 150 RPM motor sustains airflow with 1.4 A locked-rotor protection for reliability

Specifications

No published specifications for this item yet.

Questions about this item

How often should the 740 mm cross-flow impeller be cleaned to maintain the 15.5 m³/min airflow rating?

Dust buildup on the long blade surface reduces the 550 CFM output; inspect and blow out the fan every three to six months depending on environment.

Which spec caps continuous duty at 230 V — the 160 W input power or the 0.70 A rated current?

The 160 W input power at 230 V is the limiting factor; sustained operation above that level will trip thermal protection.

Does the 55 dB noise figure at 2150 RPM stay constant when the fan runs all day at 230 V?

Yes, the published 55 dB at 2150 RPM is a steady-state rating; bearing wear may add a few decibels after extended continuous use.
