Square 60 mm black frame fan with central hub and nine blades, 25 mm thick, two-wire cable visible

Fans

Fans 612NGN ebmpapst 6025 12V 6 cm case fan

SKU CH-MZW0-N7FVD

A 60 mm DC case fan delivering 40 m³/h airflow at 35 dB with a 5100 rpm sleeve bearing and PWM speed control

  • 12 V DC power suits standard PC headers
  • 5100 rpm speed delivers 40 m³/h airflow
  • 35 dB noise keeps builds quiet
  • Sleeve bearing supports continuous operation
  • 60 × 60 × 25.4 mm frame fits 6 cm mounts

Product Identity

This is a 60 mm square axial fan with a 25.4 mm depth, rated for 12 V DC operation. It draws a maximum current of 165 mA and spins at 5100 rpm to deliver 40 m³/h of airflow at a noise level of 35 dB. The unit uses a sleeve bearing and includes a speed signal wire plus end-stop and speed-limit alarms.

Fit and Limits

The fan suits builds that need a compact 6025 frame with PWM and analog control inputs, external and internal temperature sensors, and a glass-fibre reinforced structure. It is not for designs that require a ball bearing, a different voltage, or a mounting pattern outside the 60 x 60 mm footprint.

Deciding Specification

The sleeve bearing and 5100 rpm speed at 35 dB define the acoustic and longevity profile for this 6 cm frame. Buyers who need a ball bearing or a lower noise floor at this form factor should look elsewhere.

Highlights

  • 12 V DC power suits standard PC headers
  • 5100 rpm speed delivers 40 m³/h airflow
  • 35 dB noise keeps builds quiet
  • Sleeve bearing supports continuous operation
  • 60 × 60 × 25.4 mm frame fits 6 cm mounts

Specifications

No published specifications for this item yet.

Questions about this item

What does the 12 V DC supply and 165 mA maximum current cap in practice?

The fan draws up to 165 mA at 12 V DC, so the motherboard header or fan controller must supply at least that much current on its 12 V rail.

Will the 60 mm by 60 mm by 25.4 mm frame fit a standard 6025 mounting pattern?

Yes — the 60 mm square footprint and 25.4 mm depth match the common 6025 hole spacing used on many CPU coolers and chassis brackets.

How do I connect the single AWG 24 wire bundle so the speed signal and PWM control work?

Match each lead to the corresponding header pin — power, ground, tachometer output and PWM input — using the wire colours or the supplier pin-out diagram; reversing power and ground will prevent the fan from starting.
