Silver aluminium-frame axial fan, 172 by 150 by 25 mm, black blades, wire leads

Fans

Fans 5910PL-05W-B76 24V 1.95A 4100RPM 290CFM case fan

SKU CH-X2XF-YP3N0 MPN 5910PL-05W-B76

24V axial fan delivers 290CFM at 4100RPM with double ball bearings and 50000-hour service life

  • High airflow of 290 CFM for demanding cooling
  • 4100 RPM speed delivers strong static pressure of 233 Pa
  • Double ball bearing rated for 50000 hours service life
  • Operates reliably from -20 to 75 °C ambient temperature
  • Slim 172 x 150 x 25 mm aluminium frame fits tight spaces

High-airflow 24V server fan

The NMB 5910PL-05W-B76 is a 172 mm by 150 mm axial fan built for 24 V industrial and server cooling. Its double ball bearing and aluminium frame support continuous operation in medical, rail and new-energy vehicle equipment. The slim 25 mm profile fits tight chassis where high static pressure is required.

24 V power and noise envelope

At 24 V the fan draws 1.95 A rated current with an actual draw of 1.55 A, consuming 37.2 W. It spins at 4100 RPM to deliver 290 CFM (8.2 m³/min) against 233 Pa static pressure. The acoustic output reaches 65.4 dBA, so the unit suits rack or enclosure installations where airflow takes priority over quiet operation.

50 000-hour bearing life decides fit

The double ball bearing is rated for 50 000 hours at ambient temperatures from -20 °C to 75 °C. That service life determines whether the fan matches a maintenance schedule for continuous-duty server or industrial deployments. Buyers needing longer intervals between replacements should verify the rating against their duty cycle.

Highlights

  • High airflow of 290 CFM for demanding cooling
  • 4100 RPM speed delivers strong static pressure of 233 Pa
  • Double ball bearing rated for 50000 hours service life
  • Operates reliably from -20 to 75 °C ambient temperature
  • Slim 172 x 150 x 25 mm aluminium frame fits tight spaces

Specifications

No published specifications for this item yet.

Questions about this item

Should I pick the 24 V 1.95 A version or a lower‑current model?

This unit is rated 24 V at 1.95 A with an actual draw of 1.55 A; choose it when your power supply can deliver 24 V and you need the 4100 RPM airflow.

What does the 290 CFM rating mean once the fan is installed in a chassis?

It delivers 290 CFM (8.2 m³/min) at 4100 RPM with 233 Pa static pressure, so it moves a high volume of air through restrictive grilles or dense heatsinks.

What interface does the fan use and what does it limit?

It connects via standard two‑wire 24 V DC leads; the voltage fixes the 4100 RPM speed and 37.2 W power ceiling.
