Black square 12cm axial fan with clear plastic blades and wire leads

Fans

Fans 4414F/2 12025 12cm 24V 5.0W case fan

SKU CH-JZTE-2NSVF

120 mm 24 V DC axial fan delivers 170 m³/h airflow at 43 dB with ball-bearing reliability

  • 24 V DC supply suits industrial and server builds
  • 170 m³/h airflow moves heat through tight spaces
  • Ball bearing design resists wear for long service life
  • 43 dB noise level keeps background sound low
  • 119 × 119 × 25 mm frame fits standard 120 mm mounts

120 mm 24 V axial case fan

The Fans 4414F/2 is a 12025 axial fan built for 24 V DC systems. It draws 5.0 W at 2900 rpm and delivers 170 m3/h of airflow at a noise level of 43 dB. The ball-bearing motor includes polarity-reverse protection and lock-prevention features. Its PBT housing and PA impeller suit industrial and electronics cooling applications.

Verify voltage connector and mounting space

Confirm that your power source provides 24 V DC and that the fan header or wiring matches the supply. The unit measures 119 x 119 x 25 mm, so check the available mounting depth and screw-hole pattern in your chassis. Ensure the airflow direction aligns with your thermal design before installation.

Suited for 24 V industrial and embedded builds

This fan fits builders who need a compact 120 mm axial cooler for 24 V DC environments such as server enclosures, telecom gear or refrigeration units. It is not intended for standard 12 V PC headers, for silent-focused builds requiring lower noise, or for liquid-cooling radiators that demand higher static pressure.

Highlights

  • 24 V DC supply suits industrial and server builds
  • 170 m³/h airflow moves heat through tight spaces
  • Ball bearing design resists wear for long service life
  • 43 dB noise level keeps background sound low
  • 119 × 119 × 25 mm frame fits standard 120 mm mounts

Specifications

No published specifications for this item yet.

Questions about this item

Does the 12025 fan come with mounting screws or a power cable, or must they be purchased separately?

The 119 x 119 x 25 mm unit is supplied as the fan only; standard 120 mm mounting screws and a 24 V DC power lead are not included.

Should I choose the 4414F/2 model or another variant in the 4400 series for a 24 V system?

The 4414F/2 is the 24 V, 5.0 W, 2900 rpm version in the 4400 series; other variants in the same series may use different voltages or speeds, so match the 24 V requirement exactly.

What does the 170 m³/h airflow figure mean once the fan is installed in a case?

At 2900 rpm the fan moves 170 m³/h of air, producing 43 dB noise; actual throughput will depend on case restriction, filter density and any obstructions in the airflow path.
