Square metal 120 mm fan, 38 mm thick, silver finish

Fans

Fans 4184NX 120x120x38mm 24V Case Fan

SKU CH-7ME4-MH16Y

120 mm metal DC fan with 24 V nominal supply and 12–30 V range, 3200 rpm, 180 m³/h airflow, 49 dB noise, ball bearing

  • Runs on 24 V DC with 12–30 V range
  • Delivers 180 m³/h airflow at 3200 RPM
  • Operates at 49 dB(A) for quiet cooling
  • Draws only 4.9 W for energy efficiency
  • Metal housing with ball bearing for durability

Industrial-grade 24V cooling fan

The Fans 4184NX is a 120 mm square metal-bodied fan designed for 24 V DC systems. It suits equipment builders and maintenance engineers who need reliable airflow in industrial enclosures or high-temperature chassis.

180 m³/h airflow at 3200 rpm

At nominal 24 V the fan delivers 180 m³/h while drawing 145 mA and 4.9 W. The voltage range spans 12 V to 30 V, so speed and flow drop at the lower end. Noise reaches 49 dB(A) in free air and the stainless-steel ball bearing is rated for continuous operation up to the stated ambient limit.

120×120×38 mm metal frame with ball bearing

The all-metal housing and impeller resist vibration and heat better than plastic alternatives. Standard 120 mm mounting holes simplify replacement in existing cut-outs, while the 38 mm depth requires matching clearance. Two-wire DC input means no PWM control or tachometer signal is provided.

Highlights

  • Runs on 24 V DC with 12–30 V range
  • Delivers 180 m³/h airflow at 3200 RPM
  • Operates at 49 dB(A) for quiet cooling
  • Draws only 4.9 W for energy efficiency
  • Metal housing with ball bearing for durability

Specifications

No published specifications for this item yet.

Questions about this item

Will the 4184NX run on my existing 12 V fan header or do I need a 24 V supply?

The fan accepts a 12 – 30 V DC range, so it will operate from a 12 V header, but nominal speed and airflow are rated at 24 V.

What noise and airflow figures confirm the 4184NX is running correctly after installation?

At nominal 24 V the fan should deliver 180 m³/h at 3200 min⁻¹ with a noise level of 49 dB(A).

Does the 4184NX include mounting screws, a PWM cable or any accessories in the box?

Only the fan unit itself is supplied; mounting hardware and any required cables must be purchased separately.
