Square aluminium frame fan with black reinforced blades and two terminals

Fans

Fans 3610PS-20T-B30 9025 200V case fan

SKU CH-37KH-MSPF4

A 92.5 mm square tubeaxial fan with ball bearing, 34.5 CFM airflow and 38.0 dB noise at 3100 RPM

  • Delivers 34.5 CFM airflow for effective case cooling
  • Ball bearing rated for 50,000 hours at 25 °C
  • Runs at 3,100 RPM while producing 38.0 dB noise
  • Operates on 200 VAC with only 10 W power draw
  • Certified CE, CSA, TUV, UL and VDE for safety compliance

Industrial 200 V AC tubeaxial fan

The Fans 3610PS-20T-B30 is a 92.5 mm square tubeaxial fan rated for 200 V AC operation. It delivers 34.5 CFM of airflow at 3100 RPM with a ball-bearing design. The aluminium frame and polycarbonate fiberglass-reinforced blades suit industrial enclosures and server chassis that require continuous forced-air cooling.

Verify mains voltage and mounting clearance

Confirm that the target equipment supplies 200 V AC and can accommodate a 92.5 mm by 92.5 mm frame with 25.00 mm depth. The two-terminal connector must match the existing wiring harness. Ensure the operating ambient range of 14 to 158 °F matches the installation environment and that the 0.080 A draw is within the circuit capacity.

Steady 38.0 dB noise at rated load

At the rated 10.00 W the fan maintains a constant 3100 RPM and produces 38.0 dB of acoustic noise. Static pressure holds at 0.243 in H2O (60.7 Pa) without the variation seen in short-cycle testing. The ball bearing is rated for 50000 hours at 25 °C, supporting uninterrupted duty in always-on systems.

Highlights

  • Delivers 34.5 CFM airflow for effective case cooling
  • Ball bearing rated for 50,000 hours at 25 °C
  • Runs at 3,100 RPM while producing 38.0 dB noise
  • Operates on 200 VAC with only 10 W power draw
  • Certified CE, CSA, TUV, UL and VDE for safety compliance

Specifications

No published specifications for this item yet.

Questions about this item

What comes in the box with the 3610PS-20T-B30 fan and what else is needed to install it?

The fan ships as a single unit with two terminals for wiring. Mounting screws and a power cord are not included and must be sourced separately.

How do I choose between the available versions of the 3610PS-20T-B30?

Only the 200 VAC, 3100 RPM model with ball bearing is listed. There are no alternative voltage, speed or bearing options to select from.

What does the 34.5 CFM airflow figure mean once the fan is mounted in a case?

At 3100 RPM the fan moves 34.5 CFM against 0.243 in H₂O static pressure, delivering 38 dB noise within a 14–158 °F operating range.
