Black 80mm square axial case fan 15mm thick with three wire leads

Fans

Fans 3106KL-05W-B59 24V 80mm axial case fan

SKU CH-AFDY-SAPCE

An 80 mm axial case fan delivering 32.8 CFM at 34 dB with a locked-rotor sensor and ball bearing

  • 24 VDC operation suits industrial and server builds
  • 8 CFM airflow at 3000 RPM moves air through tight chassis
  • 34 dBA noise level keeps rack environments quiet
  • Ball bearing design resists wear in continuous duty cycles
  • Locked-rotor sensor alerts system before thermal damage occurs

24 V 80 mm Axial Case Fan

This 24 VDC axial fan measures 80 mm square by 15 mm thick and delivers 32.8 CFM airflow at 3000 RPM. It draws 0.16 A for 2.88 W power consumption and produces 34 dB noise. The ball bearing design includes a locked rotor sensor for monitoring.

Power Supply and Mounting Check

Verify your system provides a 24 VDC source capable of 0.16 A and a three-lead connector matching the fan termination. Confirm the mounting holes suit an 80 mm square frame with 15 mm depth and that the operating range of -10 to 50 °C fits the intended environment.

Ball Bearing Build and Three-Lead Wiring

The ball bearing construction supports continuous operation across the rated temperature span while the locked rotor sensor adds failure detection. Three leads supply power and sensor output, simplifying integration into industrial, medical or embedded cooling setups where 24 V rails are standard.

Highlights

  • 24 VDC operation suits industrial and server builds
  • 8 CFM airflow at 3000 RPM moves air through tight chassis
  • 34 dBA noise level keeps rack environments quiet
  • Ball bearing design resists wear in continuous duty cycles
  • Locked-rotor sensor alerts system before thermal damage occurs

Specifications

No published specifications for this item yet.

Questions about this item

Does the 80mm fan ship with mounting screws or a power adapter, or must I buy them separately?

The unit is supplied as the fan motor only; mounting hardware and any wiring adapters are not included and must be sourced separately.

Should I choose the 24V 0.16A ball-bearing model or look for a different voltage or bearing option?

This specific model is a 24VDC ball-bearing fan rated at 0.16A; other voltages or bearing types are different part numbers and are not covered by this listing.

What does the 32.8 CFM airflow rating mean for actual cooling inside my case?

At 3000 RPM the fan moves 32.8 CFM with 0.120 inch water column static pressure, producing 34 dB noise while drawing 2.88W.
