Black 60mm square case fan with hydraulic bearing and wire leads

Fans

Fans 2406RL-05W-M59 24V 0.18A 60mm case fan

SKU CH-X55S-AMPR0 MPN 2406RL-05W-M59

A 60 mm hydraulic-bearing case fan running at 4600 RPM with 25 CFM airflow at 22 dBA on 24 V power

  • Quiet 22 dBA noise level for low-distraction environments
  • Hydraulic bearing for smooth, long-life rotation
  • 25 CFM airflow at 4600 RPM delivers effective cooling
  • 32 W power draw keeps energy use low
  • 60 × 60 × 15 mm frame fits standard 60 mm mounts

Product Identity

This is a NMB-MAT 2406RL-05W-M59 60mm case fan with hydraulic bearing. It runs on 24V at 0.18A and draws 4.32w while spinning at 4600RPM with a ±5% tolerance. The unit measures 60x60x15mm and produces 25cfm airflow at 4.1m/s wind speed with 22dba noise output.

Suitable Users

Engineers integrating cooling into medical devices, rail vehicles, industrial cleaning equipment, new energy vehicles or supermarket systems will find the 24V supply and compact frame a direct fit. Buyers who need a standard 12V PC case fan, a larger frame size or PWM speed control should look at other models.

Capacity and Limits

The fan delivers 25cfm through a 60x15mm profile, which suits tight enclosures and targeted component cooling. At 22dba it remains quiet in noise-sensitive racks. The fixed 4600RPM speed and two-wire 24V supply mean it cannot be throttled by a motherboard header, so thermal headroom is fixed once installed.

Highlights

  • Quiet 22 dBA noise level for low-distraction environments
  • Hydraulic bearing for smooth, long-life rotation
  • 25 CFM airflow at 4600 RPM delivers effective cooling
  • 32 W power draw keeps energy use low
  • 60 × 60 × 15 mm frame fits standard 60 mm mounts

Specifications

No published specifications for this item yet.

Questions about this item

What 24 V power source does the 2406RL-05W-M59 need to run?

Connect the fan to a 24 V supply capable of at least 0.18 A; the motor draws 4.32 W at rated speed.

Will the 60×60×15 mm frame fit the same cut-out as my current 60 mm axial fan?

Yes — the housing matches the standard 6015 footprint, so existing mounting holes line up directly.

How do I confirm the 2406RL-05W-M59 is spinning at the rated 4600 RPM after installation?

Use a tachometer or motherboard fan header readout; the hydraulic bearing should report 4600 RPM ± 5 % with 25 CFM airflow at 22 dBA.
