White rectangular box camera with C/CS lens mount, 12V DC power

Eyemax

Eyemax CO-TP-270 380TVL analog camera 12V

SKU CH-ESHK-V9YFK

A 380 TVL analog box camera with 1/4″ Sony CCD, 1.0 lux low-light sensitivity, 12 V DC power and C/CS mount lens compatibility

  • 380 TV lines deliver sharp colour detail
  • 0 lux sensitivity captures clear images in low light
  • 12 V DC power simplifies installation wiring
  • C/CS mount with adapter supports flexible lens choices
  • Auto white balance, back-light compensation and gain control adapt to changing scenes

Eyemax CO-TP-270 Box Camera

The Eyemax CO-TP-270 is a standard box camera built for analogue CCTV systems. It uses a 1/4" Sony CCD sensor to deliver 380 TV lines of colour resolution. The unit operates on 12 volts DC and includes a C/CS mount with a C-mount adapter supplied.

Installers needing a basic 12V analogue camera

This camera suits installers maintaining or expanding existing coaxial surveillance systems that accept a standard box form factor. It is not for buyers who need an IP network camera, a dome or bullet housing, or a unit with integrated infrared illumination for zero-light scenes.

380 TVL resolution on a Sony CCD

The 1/4" Sony CCD produces 380 TV lines of colour resolution with a minimum illumination of 1.0 lux at F1.2. Electronic shutter control, auto tracing white balance, back light compensation and auto gain control adjust the image automatically. The C/CS mount accepts a wide range of separate lenses.

Highlights

  • 380 TV lines deliver sharp colour detail
  • 0 lux sensitivity captures clear images in low light
  • 12 V DC power simplifies installation wiring
  • C/CS mount with adapter supports flexible lens choices
  • Auto white balance, back-light compensation and gain control adapt to changing scenes

Specifications

BrandEyemax
ModelCO-TP-270

Questions about this item

How can I confirm the Eyemax CO-TP-270 is working correctly after connecting it to a 12V DC supply?

Verify a stable video signal on your monitor or DVR showing 380 TV lines of colour resolution; the on-screen image should remain clear down to 1.0 lux at F1.2 with AGC active and the auto white balance and back-light compensation adjusting automatically.

What comes with the Eyemax CO-TP-270 and what must I purchase separately?

The box contains the white-cased camera body with 1/4" Sony CCD sensor and a C-mount adapter for CS-mount lenses; a C/CS-mount lens and a 12V DC power supply are not included and must be bought separately.

Which resolution figure should I use to choose between versions of this camera?

The model delivers 380 TV lines of colour resolution; use that figure — not the 330 TV line reference — when comparing versions or planning the installation.
