Silver rack-mount network switch with front ports and SFP cages

Extreme Networks

Extreme Networks 5420F-24P-4XE 24-port 30W PoE network switch

SKU CH-V17E-F16F6 MPN 5420F-24P-4XE

Managed 24-port PoE switch with four 1/10Gb SFP+ uplinks and 30W per port

  • Network Management TypeManaged
  • Primary Ports24 x 10/100/1000BASE-T 802.3at (30W) ports • Full / Half-Dup
  • VLAN SupportYes
  • PoEAll 5420 models support 30W, 60W, and 90W PoE that conforms
  • StackableYes
  • DimensionsHeight: 43.2 mm (1.7 in.) Width: 442.0 mm (17.4 in.) Depth:

Model 5420F-24P-4XE

Struck-through versions exist but are not stocked here.

  • Managed switch with 24 PoE+ ports delivering 30W each
  • Four 1/10Gb SFP+ uplinks plus two SFP-DD stacking ports
  • Stack up to eight units for 208Gbps aggregated bandwidth
  • Cloud onboarding via ExtremeCloud IQ with zero-touch provisioning
  • Dual OS choice: Switch Engine or Fabric Engine at startup

24-port PoE+ switch for managed edges

The Extreme Networks 5420F-24P-4XE is a managed Universal Edge switch with twenty-four 10/100/1000BASE-T ports that deliver up to 30 W per port under IEEE 802.3bt. Four 1/10 Gb SFP+ uplinks and two SFP-DD stacking ports provide high-speed aggregation. It runs either Switch Engine (EXOS) or Fabric Engine (VOSS) and is managed through Extreme Platform ONE or ExtremeCloud IQ.

Ideal for wired access layers needing PoE

This switch suits network teams that want a single hardware platform with selectable OS and cloud-based zero-touch provisioning. It fits deployments requiring MACsec-capable ports and up to eight units in a high-speed stack. Buyers needing 60 W or 90 W per port on every interface simultaneously should verify the total power budget before committing. Sites without fibre uplinks or stacking requirements may find simpler fixed-configuration models more cost-effective.

208 Gbps aggregated bandwidth decides fit

The 5420F-24P-4XE delivers 208 Gbps of aggregated switching bandwidth and a frame forwarding rate of 154.8 Mpps. If your design requires higher aggregate throughput or larger forwarding capacity, you must step to a larger chassis or a higher-tier model in the series.

Highlights

  • Managed switch with 24 PoE+ ports delivering 30W each
  • Four 1/10Gb SFP+ uplinks plus two SFP-DD stacking ports
  • Stack up to eight units for 208Gbps aggregated bandwidth
  • Cloud onboarding via ExtremeCloud IQ with zero-touch provisioning
  • Dual OS choice: Switch Engine or Fabric Engine at startup

Specifications

BrandExtreme Networks
Series5420
Model5420F-24P-4XE
Network Management TypeManaged
Primary Ports24 x 10/100/1000BASE-T 802.3at (30W) ports
• Full / Half-Duplex(autosensing)
• MACsec-capable
4 x 1/10Gb SFP+ uplink ports(unpopulated)
• MACsec-capable
2 x Stacking/SFP-DD ports* (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
2 x USB A ports for management or external USB flash
1 x USB Micro-B console port
VLAN SupportYes
PoEAll 5420 models support 30W, 60W, and 90W PoE that conforms with IEEE 802.3bt. This enables the 5420 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5420 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation
StackableYes
DimensionsHeight: 43.2 mm (1.7 in.)
Width: 442.0 mm (17.4 in.)
Depth: 287.02 mm (11.3 in.)
Weight4.64 kg (10.23 lb.)
Shipping weight5.94 kg
Package size13 × 13 × 13 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is the maximum PoE power per 10/100/1000BASE-T port on the 5420F-24P-4XE?

Each of the 24 copper ports delivers up to 90W under IEEE 802.3bt, with 30W, 60W and 90W modes supported.

What rack space and depth does the 5420F-24P-4XE require?

The unit is 1.7 in tall (1 U), 17.4 in wide and 11.3 in deep, fitting a standard 19 in rack.

How do you stack multiple 5420F-24P-4XE switches and what cabling is needed?

Use the two built-in SFP-DD stacking ports with qualified SFP+/SFP-DD direct-attach cables or optics; up to eight switches can be stacked when running Switch Engine.
