Black aluminium SDI to HDMI converter box 90x55x20mm with SDI in, SDI loop-out, HDMI out, power cable

ESTONE

ESTONE SDI to HDMI Converter 3G/HD/SD-SDI Audio De-embedder (OZH5)

SKU CH-8KAA-N8ZNJ

Converts 3G, HD and SD-SDI signals to HDMI up to 1080p60 with simultaneous SDI loop-through and stereo audio de-embedding

  • TypeSDI to HDMI Converter
  • Connector A1 x SDI input
  • Connector B1 x SDI output, 1 x HDMI output
  • Package ContentsSDI to HDMI Converter * 1 USB Charge Cable * 1 Power Adapter
  • View on HDMI displays with auto format detection
  • Loop-through SDI output for simultaneous monitoring
  • Supports SD-SDI, HD-SDI and 3G-SDI signals up to 2.970 Gbps
  • Outputs up to 1080p at 24, 25, 30, 50 or 60 Hz
  • Compact aluminium alloy housing measures 90 x 55 x 20 mm

SDI to HDMI conversion with loop-through

The ESTONE OZH5 converts SD-SDI, HD-SDI and 3G-SDI signals to HDMI while passing the original SDI stream through a loop output. It accepts one SDI input and provides one HDMI output plus one SDI output for simultaneous monitoring. The unit is aimed at video engineers and broadcasters who need to view professional SDI sources on common HDMI displays.

Bit-rate ceiling and supported formats

The converter handles data rates up to 2.970 Gbps and auto-detects the incoming standard. Supported input and output resolutions reach 1080p at 60 Hz, with additional compatibility for 1080i at 50/60 Hz, 720p at 50/60 Hz, 480p60, 480i50 and 576i50. It is not bi-directional and cannot convert HDMI back to SDI.

Aluminium enclosure and power requirements

The black aluminium alloy chassis measures 90 x 55 x 20 mm and draws power from an included DC 5 V 1 A adapter via a USB charge cable. One SDI input, one SDI loop output and one HDMI output are the only connections; there are no additional audio breakout ports or network interfaces.

Highlights

  • View on HDMI displays with auto format detection
  • Loop-through SDI output for simultaneous monitoring
  • Supports SD-SDI, HD-SDI and 3G-SDI signals up to 2.970 Gbps
  • Outputs up to 1080p at 24, 25, 30, 50 or 60 Hz
  • Compact aluminium alloy housing measures 90 x 55 x 20 mm

Specifications

TypeSDI to HDMI Converter
Connector A1 x SDI input
Connector B1 x SDI output, 1 x HDMI output
Package ContentsSDI to HDMI Converter * 1
USB Charge Cable * 1
Power Adapter * 1
User Manual * 1

Questions about this item

Should I choose the model with loop-through SDI output or a simpler SDI-to-HDMI-only unit?

This unit includes an SDI loop-through output so you can feed an SDI monitor while simultaneously driving an HDMI display.

What does the 1080p/60 Hz headline figure mean when I connect it to my monitor?

The converter accepts SDI signals up to 1080p at 60 Hz and reproduces the same resolution and frame rate on the HDMI output.

Does the 2.97 Gbps SDI interface limit the resolutions I can actually use?

The 2.97 Gbps bit-rate supports SD-SDI, HD-SDI and 3G-SDI formats including 1080p at 24, 25, 30, 50 and 60 Hz, 1080i at 50 and 60 Hz, 720p at 50 and 60 Hz, 480p60, 480i50 and 576i50.
