Black rectangular HDMI splitter with sixteen output ports

ESTONE

ESTONE OZF13 1x16 HDMI Splitter 4K 30Hz

SKU CH-2Y7J-MHSS8

Distributes one HDMI source to 16 displays at 4K 30 Hz with 12-bit colour and multi-channel audio

  • TypeHDMI Splitters
  • Changer TypeHDMI
  • Ports16
  • AudioYes
  • ColorBlack
  • SpecificationsMax Bandwidth:320MHz Max Transmission Bandwidth:3.2Gbps HDMI
  • Mirrors one source to 16 displays simultaneously
  • Delivers 4K resolution at 30 Hz refresh rate
  • Handles 12-bit deep colour and full 3D video
  • Passes Dolby TrueHD and DTS-HD master audio
  • Powered by included 12 V 5 A adapter

16-output 4K HDMI splitter for multi-display setups

This ESTONE OZF13 unit takes a single HDMI source and mirrors it across 16 displays simultaneously. It is built for trade shows, conference rooms, education centres and home-theatre installations where identical content must reach many screens at once. The package includes the splitter, a 12 V DC power supply and a user manual.

HDMI 1.4b bandwidth caps resolution at 4K 30 Hz

The splitter conforms to HDMI 1.4b with a maximum transmission bandwidth of 3.2 Gbps and a 320 MHz pixel clock. That limits 3840 x 2160 output to 30 Hz, while lower resolutions such as 1080p can run at higher refresh rates. It does not support 4K at 60 Hz or the extended colour spaces and HDR metadata found in later HDMI versions.

Simple rack-mount install.

The compact metal chassis measures 5.59 x 3.15 x 1.26 inches and weighs 3.2 ounces, so it fits easily on a shelf or in a rack tray. Connect the source, attach up to 16 displays, plug in the supplied 12 V 5 A adapter and power on. Most issues arise when long or thin HDMI cables push the 3.2 Gbps link past its reliable distance, causing sparkles or drop-outs on the farthest screens.

Highlights

  • Mirrors one source to 16 displays simultaneously
  • Delivers 4K resolution at 30 Hz refresh rate
  • Handles 12-bit deep colour and full 3D video
  • Passes Dolby TrueHD and DTS-HD master audio
  • Powered by included 12 V 5 A adapter

Specifications

BrandESTONE
SeriesOZF13
ModelOZF13
Part NumberOZF13
TypeHDMI Splitters
Changer TypeHDMI
Ports16
AudioYes
ColorBlack
SpecificationsMax Bandwidth:320MHz
Max Transmission Bandwidth:3.2Gbps
HDMI Version: HDMI 1.4b
Power Adapter Format: DC 12V/5A
Support audio format: DTS-HD/Dolby-trueHD/ DTS/Dolby-AC3/DSD
Input Connector1 HDMI input
Output Connector16 HDMI Output
Maximum Resolutions3840 x 2160
FeaturesSupports high resolutions up to ultra HD 4Kx2K, including 480i/p, 576i/p, 720i/p, 1080i, 1080p;
Supports 12-bit Deep Full HD, Full 3D and 4Kx2K video;
Supports audio format such as LPCM7.1, Dolby True HD, Dolby DTS Plus and DTS-HD Audio;
Input support: Computer, PS3, PS4, Xbox, Blu-ray DVD player, STB etc;
Output support: projectors, Full HDTVs, TV, monitor, etc.
Dimensions5.59 x 3.15 x 1.26 inches
Weight3.2 ounces
Package Quantity1
Package Contents1 x 4K 16 Port HDMI Splitter
1 x 12V DC Power Supply
1 x User Manual

Questions about this item

Is the ESTONE OZF13 available in any other port counts besides the 16-output version?

The OZF13 is sold as a fixed 1-input, 16-output splitter; no other port-count variants are listed for this model.

What does the 4K 30Hz rating mean when I connect this splitter to my displays?

Each of the 16 outputs can mirror the source at up to 3840×2160 resolution at 30 Hz, so all screens show the same 4K image at that refresh rate.

How does the HDMI 1.4b interface limit the bandwidth on this 1×16 splitter?

HDMI 1.4b caps the link at 3.2 Gbps and 320 MHz bandwidth, which supports 4K at 30 Hz but not higher 4K refresh rates or 4K at 60 Hz.
