Black rectangular HDMI splitter with one input and two output ports

ESTONE

ESTONE OZF12-2 1x2 HDMI 2.0 Splitter 4K 60Hz 18Gbps

SKU CH-MSW0-9V5VC

Splits one HDMI source to two displays at 3840x2160 60Hz with 18Gbps bandwidth and HDCP 2.2

  • TypeHDMI Splitters
  • Changer TypeHDMI
  • Ports2
  • AudioYes
  • ColorBlack
  • SpecificationsHDMI version:HDMI 2.0 HDMI resolution:up to 3840x2160P/60Hz
  • Sends one 4K source to two displays simultaneously
  • 4K 60 Hz via HDMI 2.0 and 18 Gbps bandwidth
  • 30/36/48-bit deep colour with HDR for richer images
  • Dolby TrueHD, DTS-HD and DSD audio pass-through
  • Four EDID modes ensure reliable handshake with consoles, PCs and streamers

1x2 HDMI 2.0 splitter for dual displays

The ESTONE OZF12-2 takes one HDMI source and duplicates the signal to two displays at up to 3840x2160 resolution and 60Hz refresh rate. It handles 18Gbps bandwidth with support for 30, 36 and 48 bit deep colour and audio formats including DTS-HD and Dolby TrueHD. The unit includes an AC power adaptor and measures 5.59 x 3.15 x 1.26 inches.

Replaces basic switchers when simultaneous output

Unlike a simple A/B switch that shows only one screen at a time, this splitter drives both outputs together for mirroring or Windows extend mode. The jump is worth it when you need identical content on a monitor and a projector, or on two TVs in different rooms, without swapping cables. Four selectable EDID modes help maintain a stable handshake with mixed sink devices.

Plug-and-play with external power

Connect the source to the single input and the two displays to the outputs, then attach the supplied AC adaptor. The splitter draws power from the adaptor, not from the HDMI ports, which avoids dropouts on laptops or streaming sticks that cannot supply enough current. The most common issue is a mismatch between the source resolution and the lowest-capability display; setting the EDID switch to the correct mode usually resolves it.

Highlights

  • Sends one 4K source to two displays simultaneously
  • 4K 60 Hz via HDMI 2.0 and 18 Gbps bandwidth
  • 30/36/48-bit deep colour with HDR for richer images
  • Dolby TrueHD, DTS-HD and DSD audio pass-through
  • Four EDID modes ensure reliable handshake with consoles, PCs and streamers

Specifications

BrandESTONE
SeriesOZF12-2
ModelOZF12-2
Part NumberOZF12-2
TypeHDMI Splitters
Changer TypeHDMI
Ports2
AudioYes
ColorBlack
SpecificationsHDMI version:HDMI 2.0
HDMI resolution:up to 3840x2160P/60Hz
Support video color format:30/36/48 bit deep color
Support audio format:DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD HD(HBR)
Max bandwidth:1536MHz
Max baud rate:18Gbps
Input cable distance:<5m AWG26 HDMI standard cable
Output cable distance:<5m AWG26 HDMI standard cable
Max working current:1200mA
Power Adapter Format:output: DC5V/1A
Dimension :58x49x11mm
Weight:130g
4K HDMI Splitter 1x2 2160P 60HZ HDMI2.
Input Connector1 HDMI input
Output Connector2 HDMI
Maximum Resolutions3840 x 2160
Bandwidth18Gbps
FeaturesHDMI Splitter 1x2: 4k 1x2 HDMI Splitter distributes 1 HDMI source duplicate to 2 different HDMI displays simultaneously. Transfer impressive and high-definition video and audio without loss and delay. (Duplicate input signal only, NOT support Extend)
High-grade Configuration: The 4K HDMI splitter supports HDCP2.2, HDMI2.0b, EDID, 3D, RGB 4:4:4, Ultra HD Max Resolution 3840*2160 4k@60Hz. The most high-grade configuration gives you the most extreme enjoyment. It support doby vision, but it requires your display device support doby vision, too.
Wide Compability: This 4k HDMI splitter 1
Dimensions5.59 x 3.15 x 1.26 inches
Weight3.2 ounces
Package Quantity1
Package Contents1.1x2 HDMI 2.0 Splitter HDCP 2.2 x1
2.AC Power Adaptor x1
3.User Manual x1

Questions about this item

What are the exact dimensions of the ESTONE OZF12-2 splitter so I can check it fits my AV rack?

The unit measures 5.59 x 3.15 x 1.26 inches and weighs 3.2 ounces, so it sits on a shelf or mounts with Velcro in a tight rack space.

Does the splitter need the included AC power adaptor to work, or can it run from the HDMI source alone?

It requires the supplied AC power adaptor; connect the adaptor first, then plug in the HDMI source and both displays — skipping the power step is the most common reason for no signal.

The box lists four EDID modes — how do I pick the right one later if I change a display?

Use the EDID mode button on the front panel to cycle through the four presets; the LED indicates the active mode, so you can reselect whenever you swap a TV or projector.
