Green PCIe x1 expansion card with mSATA slot and SATA port, full-height bracket

EN-Labs

EN-Labs PCIEMSATA PCIe x1 to mSATA + SATA III Adapter

SKU CH-8456-KSW2Y

Adds an mSATA SSD and a SATA drive simultaneously through one PCIe x1 slot using an ASM1061 controller

  • SpecificationsPCIe - PCIe-X1,support PCIE X2,X4,X8,X16 Output interface -
  • FeaturesExtend SATA 3.0+mSATA data interfaces, and support more stor
  • Package Contents1 x PCIe to mSATA + SATA card,1 x Driver CD
  • Adds mSATA and SATA 3.0 ports via a PCIe x1 slot
  • ASM1061 controller delivers up to 6 Gbps transfer speed
  • Fits 27 mm and 50 mm mSATA SSDs with four mounting holes
  • Supports two independent SATA channels plus ATAPI optical drives
  • Works with Windows, Linux and legacy OS without extra drivers

PCIe x1 to mSATA and SATA III Adapter

This EN-Labs expansion card adds one mSATA slot and one SATA III port through a single PCIe x1 connection. It uses the ASMedia ASM1061 controller and fits standard desktop profiles. The adapter supports both 27 mm half-height and 50 mm full-height mSATA SSDs. A driver CD is included for operating system installation.

Who this suits and who should look elsewhere

Builders who want to add an mSATA SSD and a SATA hard drive or optical drive at the same time will find the dual connectors useful. The card also supports booting from the attached drives and hot-swap operation. It is not for users who need to connect Mini PCI-E, 1.8-inch micro SATA or Airbook SSD devices.

The deciding specification

The board provides a single-lane PCIe 1.0 link that carries two independent SATA III channels with a maximum transfer rate of 6 Gbps. This bandwidth ceiling determines whether the adapter can meet the throughput needs of the attached storage.

Highlights

  • Adds mSATA and SATA 3.0 ports via a PCIe x1 slot
  • ASM1061 controller delivers up to 6 Gbps transfer speed
  • Fits 27 mm and 50 mm mSATA SSDs with four mounting holes
  • Supports two independent SATA channels plus ATAPI optical drives
  • Works with Windows, Linux and legacy OS without extra drivers

Specifications

BrandEn-Labs
ModelPCIEMSATA
SpecificationsPCIe - PCIe-X1,support PCIE X2,X4,X8,X16 Output interface - mSATA + SATA III OS - Windows10/8/7(32/64?)/ Vista(32/64?)/ XP/2003/2008/linux
FeaturesExtend SATA 3.0+mSATA data interfaces, and support more storage devices. Built with Stable and reliable chipset ASMedia ASM1061. Compliant for Serial ATA III specification, transfer speed up to 6Gbps, backwards SATA 3Gbps and SATA 1.5Gbps Compliant for Single-Lane (x1) PCI Express specification revision 1.0. Supports 27mm half-height & 50mm full-height mSATA SATA SSD. Supports two independent SATA channels. Supports ATAPI devices: CD-ROM; DVD-ROM; etc. Supports boot function. Supports hot swapping. One 7 pin SATA & one 52 pin mSATA connectors available. 2 screws & 4 holes available f
Package Contents1 x PCIe to mSATA + SATA card,1 x Driver CD

Questions about this item

Does the ASM1061 controller generate noticeable heat or noise during continuous operation?

The card uses a passive ASM1061 controller with no fan, so it runs silently; heat output is minimal and handled by normal case airflow.

What drive lengths and screws are needed to secure an mSATA SSD on this card?

The board accepts 27 mm half-height and 50 mm full-height mSATA SSDs and includes two screws for the four mounting holes.

Will a SATA 3.0 Gbps hard drive work at full speed when connected alongside an mSATA SSD?

Yes, the ASM1061 provides two independent SATA III channels, so a 3.0 Gbps drive runs at its rated speed while the mSATA device operates simultaneously.
