Black plastic 90 degree hydraulic elbow adapter with threaded ends

Eaton

Eaton Aeroquip 2024-6-5S 90° Elbow Hydraulic Adapter

SKU CH-P1B1-QASMG

90-degree elbow hydraulic adapter with 3/8-18 NPTF male and 1/2-20 JIC female threads, rated to 8000 psi

  • 90° elbow routes hydraulic lines in tight spaces
  • 8,000 psi rating handles demanding pressure requirements
  • 3/8-18 NPTF threads connect directly to standard fittings
  • 12 in overall length fits compact installations
  • Black finish resists corrosion in harsh environments

90° Elbow Hydraulic Adapter

The Eaton Aeroquip 2024-6-5S is a rigid 90 degree elbow hydraulic hose adapter built for hydraulic systems. It connects a 3/8-18 NPTF thread to a 1/2-20 MJIC thread in a compact black plastic body. The fitting suits installers routing hydraulic lines in tight spaces where a straight adapter cannot fit.

Replaces straight fittings in confined routing

Use this elbow when a straight adapter forces hose kinks or exceeds bend-radius limits in the machine layout. The jump is worth it when the plumbing path changes direction sharply and a single rigid elbow eliminates an extra joint. It is not for systems that require a swivel connection or crimpable hose ends.

NPTF thread sealing and pressure ceiling

The adapter relies on NPTF dry-seal threads at both ends and carries no O-ring, so sealing quality depends on thread engagement and sealant choice. Maximum working pressure is 8 000 psi, and overall length is 1.12 in. The plastic construction limits suitability for high-temperature or high-vibration environments where metal fittings are specified.

Highlights

  • 90° elbow routes hydraulic lines in tight spaces
  • 8,000 psi rating handles demanding pressure requirements
  • 3/8-18 NPTF threads connect directly to standard fittings
  • 12 in overall length fits compact installations
  • Black finish resists corrosion in harsh environments

Specifications

BrandEATON AEROQUIP

Questions about this item

What thread sizes do the 90° elbow ports use?

The adapter has a 3/8-18 NPTF male thread on one end and a 1/2-20 MJIC male thread on the other.

How do I install the 3/8-18 NPTF end without leaking?

Apply PTFE tape or pipe sealant to the tapered threads and tighten to the recommended torque for 3/8 NPTF.

Will the O-ring on the MJIC side need periodic replacement?

The MJIC seal uses a metal-to-metal flare seat, so no O-ring is present to replace.
