Gray rectangular base station with four directional antennas, 163 by 89 mm, 1.26 kg

DJI

DJI D-RTK 3 Multifunction Base Station RTK3 M-03331 Gray

SKU CH-EVZH-Z7FYZ

A multifunctional base station providing centimeter-level positioning for multiple drones and extending operational range in relay mode

  • ColorGray
  • TypeRelay Station
  • CompatibilityYes
  • SpecificationsSatellite Reception Frequencies GPS: L1C/A, L2C, L5 BDS: B1I
  • FeaturesThe all-new D-RTK 3 multifunctional base station can serve a
  • Package Content1. D-RTK 3 Multifunction Base Station × 1 2. Spare OcuSync D

Model O4 Ground Station

  • Centimeter-level positioning for multiple drones using multi-constellation satellite reception
  • Relay station mode extends operational range beyond line-of-sight obstacles
  • Integrated high-performance antenna and receiver module tracks GPS, BDS, Galileo, GLONASS, QZSS and L-Band signals
  • Rover mode with DJI Industry Apps and SmartMap enables high-precision aerial surveying workflows
  • Compact 163 × 89 mm form factor weighs 1.26 kg and includes four spare directional antennas

Centimeter-level positioning for multiple drones

The DJI D-RTK 3 Multifunction Base Station serves as a reference station delivering centimeter-level positioning accuracy for multiple drones simultaneously. It tracks signals from GPS, BDS, Galileo, GLONASS, QZSS and L-Band constellations. A new rover mode works with DJI Industry Apps and DJI SmartMap to create a complete high-precision aerial surveying workflow. Survey teams and enterprise operators gain a single device for both positioning and data collection tasks.

Relay station mode extends operational range

When configured as a relay station, the unit extends the drone’s operational range by bridging the link between the remote controller and the aircraft. The station must be deployed in an elevated, unobstructed location to overcome signal blockage. Built-in high-performance sensors continuously analyze device position and orientation to maintain link stability. Measurement accuracy depends on open sky conditions, low ionospheric activity and minimal electromagnetic interference.

Rugged gray housing with directional antenna kit

The gray chassis measures 163 by 89 mm excluding antennas and weighs 1.26 kg. Four spare OcuSync directional antennas are included for field replacement or configuration changes. A single A-C data cable provides the wired connection interface. All rubber plugs on the airframe must be properly installed to maintain environmental sealing during outdoor deployment.

Highlights

  • Centimeter-level positioning for multiple drones using multi-constellation satellite reception
  • Relay station mode extends operational range beyond line-of-sight obstacles
  • Integrated high-performance antenna and receiver module tracks GPS, BDS, Galileo, GLONASS, QZSS and L-Band signals
  • Rover mode with DJI Industry Apps and SmartMap enables high-precision aerial surveying workflows
  • Compact 163 × 89 mm form factor weighs 1.26 kg and includes four spare directional antennas

Specifications

BrandDJI
ModelRTK3
Part NumberM-03331
ColorGray
TypeRelay Station
CompatibilityYes
SpecificationsSatellite Reception Frequencies
GPS: L1C/A, L2C, L5
BDS: B1I, B2I, B3I, B1C, B2a, B2b
Galileo: E1, E5a, E5b, E6
GLONASS: L1, L2
QZSS: L1C/A, L2C, L5
L-Band
Roaming Station Mode Accuracy (Fixed Measurement): Horizontal: 0.8 cm + 1 ppm (RMS); Vertical: 1.5 cm + 1 ppm (RMS)
Tilt Measurement: Angle Range: 0° to 60°
Horizontal: 8 mm + 0.7 mm/° of tilt (accuracy < 2 cm within 30°)
Maximum Effective Signal Range (Relay Station Mode, no interference, no obstruction)
FeaturesThe all-new D-RTK 3 multifunctional base station can serve as a reference station to enable centimeter-level positioning for multiple drones, and can also extend the drones’ operational range when operating in relay station mode.
Package Content1. D-RTK 3 Multifunction Base Station × 1
2. Spare OcuSync Directional Antennas × 4
3. A-C Data Cable × 1
Dimensions163 × 89 mm (excluding the OcuSync directional antenna)
Weight1.26kg

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I set up the D-RTK 3 base station for relay mode, and what step do people skip?

Mount the four directional antennas, connect the A-C data cable, place the unit on an elevated, unobstructed spot, and ensure all rubber plugs are properly installed — the plugs are often forgotten.

What parts will need replacement after extended field use?

The four spare OcuSync directional antennas supplied in the box are the primary consumable items for long-term operation.

What limits relay range first during sustained operation?

The relay station must be deployed in an elevated, unobstructed location; signal obstruction between the remote controller and the aircraft is the first limiting factor.
