Small white rectangular PoE extender with two RJ45 ports

DiySecurityCameraWorld

DiySecurityCameraWorld DSC-PoE-E1 PoE Extender 120m surveillance accessory

SKU CH-M492-AHVK2

Extends Ethernet and PoE power up to 120 metres over Cat5 cable with 13 W input and 12.2 W output

  • TypePoE Externder/PoE Repeater
  • SpecificationsComply with 10/100 BASE-TX, IEEE802.3af (PoE). Power input f
  • FeaturesPoE Extenders can increase the transmission distance for Eth
  • Package Contents1
  • Extends PoE power and data up to 120 metres over Cat5 cable
  • Delivers 12.2 W output from a 13 W PoE input for IP cameras
  • Plug-and-play operation with no configuration required
  • Compliant with IEEE 802.3af and 10/100 BASE-TX standards
  • 400 Mbps switching capacity with 2 K MAC address table

PoE Extender for IP Cameras

The DSC-PoE-E1 is a single-port Power over Ethernet extender built for IP camera installations. It repeats both data and PoE power over Cat5 UTP cable, allowing a camera to sit up to 120 metres from the source switch. The unit complies with IEEE 802.3af and requires no configuration.

100 Mbps and 13 W input ceiling

The extender operates at 10/100BASE-TX speeds, so the link tops out at 100 Mbps with a switching capacity of 400 Mbps. PoE input is limited to 13 W and the forwardable output drops to 12.2 W, which restricts the device to standard PoE cameras rather than PoE+ or higher-power models.

12.2 W output decides camera compatibility

Only cameras drawing 12.2 W or less can be powered reliably through this extender. Installations that need more power per port or gigabit data rates will require a different solution.

Highlights

  • Extends PoE power and data up to 120 metres over Cat5 cable
  • Delivers 12.2 W output from a 13 W PoE input for IP cameras
  • Plug-and-play operation with no configuration required
  • Compliant with IEEE 802.3af and 10/100 BASE-TX standards
  • 400 Mbps switching capacity with 2 K MAC address table

Specifications

BrandDiySecurityCameraWorld
ModelDSC-PoE-E1
TypePoE Externder/PoE Repeater
SpecificationsComply with 10/100 BASE-TX, IEEE802.3af (PoE). Power input for single port is 13W. Power output for single port is 12.2W.
FeaturesPoE Extenders can increase the transmission distance for Ethernet data and PoE power up to 120m via Cat5 UTP cable.
Package Contents1

Questions about this item

Should I pick the single-port DSC-PoE-E1 or a multi-port model for my IP camera run?

The DSC-PoE-E1 provides one PoE input and one PoE output, extending power and data for a single camera up to 120 metres over Cat5 UTP cable.

What does the 12.2 W output figure mean when the extender is installed in my system?

It delivers up to 12.2 W to the connected camera after the extender's own consumption, compliant with IEEE 802.3 af, so most standard PoE cameras will operate normally.

How does the 10/100BASE-TX interface limit real-world throughput on this extender?

The 10/100 Mbit/s ports and 400 Mbit/s switching capacity cap camera traffic at Fast Ethernet speeds, which is typical for 1080p or lower-resolution IP cameras.
