Silver 1U 19-inch rack unit with sixteen output pairs and LED indicators

DiySecurityCameraWorld

DiySecurityCameraWorld 16ch 12V 13A rack-mount power supply

SKU CH-6J19-AQY1K

A 12 V DC, 16-channel rack-mount power supply delivering 13 A total with individual PTC-fused outputs and LED status indicators

  • TypePower Supply
  • Powers 16 cameras from a single 13 A supply
  • 12 V DC regulated output keeps every camera in sync
  • Individual PTC fuses auto-reset after a short is cleared
  • Red LED per channel shows instantly which line has failed
  • 1U 19-inch rack chassis fits standard cabinets without extra hardware

16-channel CCTV power supply

This rack-mount unit delivers 12 V DC across sixteen individually fused outputs for analog security cameras. A total continuous current of 13 A is available, with each channel limited to 1.25 A. It accepts 110 V AC input and includes an on/off switch.

Per-channel current limit and rack standard

Each output is protected by a resettable PTC fuse that caps draw at 1.25 A, so cameras needing more current per channel cannot be supported. The chassis fits a standard EIA 19-inch rack and occupies 1U of vertical space.

Input voltage and camera count check

Verify that your mains supply matches the 110 V AC rating before installation. Confirm that sixteen outputs are sufficient for your camera layout and that no single camera exceeds the 1.25 A per-channel ceiling.

Highlights

  • Powers 16 cameras from a single 13 A supply
  • 12 V DC regulated output keeps every camera in sync
  • Individual PTC fuses auto-reset after a short is cleared
  • Red LED per channel shows instantly which line has failed
  • 1U 19-inch rack chassis fits standard cabinets without extra hardware

Specifications

BrandDiySecurityCameraWorld
TypePower Supply

Questions about this item

Should I pick the 16-channel unit or a smaller supply for my install?

Choose the 16-channel model when you need to power up to sixteen cameras from one rack-mount box; it delivers 12 V DC across 16 fused outputs with a 13 A total budget.

What does the 13 A total rating mean when the cameras are running?

The 13 A limit is shared across all sixteen outputs, so the combined draw of every connected camera must stay at or below 13 A; each channel can supply up to 1.25 A.

How does the 120 V AC input and 19-inch rack format affect installation?

The unit plugs into a standard 120 V AC circuit and fits a 1U EIA 19-inch rack, so it mounts in a typical server cabinet without extra adapters.
