Small black rectangular camera board with round lens and silver screw holes on green PCB

DFRobot Raspberry Pi 5MP Camera Module OV5647 1080p IR-Cut Adjustable Focus

SKU CH-S31D-K855K

5 MP OV5647 sensor captures 2592 × 1944 stills and 1080p30 video with automatic IR-cut day/night switching and adjustable focus via CSI

  • Typewebcam
  • ColorBlack
  • CPU TypeARM Cortex
  • Captures 2592 x 1944 still images with the 5MP OV5647 sensor
  • Records 1080p video at 30 fps and 720p at 60 fps for smooth footage
  • Automatic IR-cut switching delivers clear day and night vision
  • Adjustable 3.6 mm focal length lets you set the 72-degree field of view
  • Connects via CSI interface for direct high-bandwidth link to the Raspberry Pi processor

Camera Module with Adjustable Focus

This 5MP camera module uses the OV5647 sensor and connects through the Raspberry Pi CSI interface. It captures 2592 x 1944 pixel still images and records 1080p video at 30 fps, 720p at 60 fps, or 640 x 480 at 60/90 fps. The lens focal length is adjustable at 3.6 mm with a 72 degree field of view.

CSI Interface Bandwidth Limit

The dedicated CSI bus carries pixel data directly to the processor, but its throughput caps the maximum frame rates at the listed resolutions. Higher resolutions or faster frame rates than 1080p at 30 fps are not supported by this sensor and interface combination. The module requires a Raspberry Pi with a standard Camera Module port.

5MP Resolution and Night Vision Headroom

The 5MP sensor handles 1080p streaming and 2592 x 1944 stills comfortably for monitoring and vision projects. Automatic IR-cut switching extends usability into low light when an infrared LED is connected to the 3.3 V output. It cannot deliver 4K output or global-shutter capture for fast motion.

Highlights

  • Captures 2592 x 1944 still images with the 5MP OV5647 sensor
  • Records 1080p video at 30 fps and 720p at 60 fps for smooth footage
  • Automatic IR-cut switching delivers clear day and night vision
  • Adjustable 3.6 mm focal length lets you set the 72-degree field of view
  • Connects via CSI interface for direct high-bandwidth link to the Raspberry Pi processor

Specifications

BrandDFRobot
ModelRaspberry Pi 5MP
Typewebcam
ColorBlack
CPU TypeARM Cortex

Questions about this item

Which Raspberry Pi models work with this camera module?

The module connects through the CSI interface and is compatible with Raspberry Pi 4, 3B+, 3, 2, 1, B+, A+, and Zero when using the correct ribbon cable for the smaller port.

What resolution and frame rates can the OV5647 sensor actually deliver?

It captures 2592 x 1944 still images and records 1080p at 30 fps, 720p at 60 fps, and 640 x 480 at 60 or 90 fps.

What does the CSI interface limit in practice?

The dedicated CSI bus carries pixel data directly to the processor, so bandwidth is not a bottleneck for the supported 1080p30 and 720p60 modes.
