Silver 4U rack server with front bezel, twenty-four 2.5 inch drive bays and Dell badge

DELL

DELL PowerEdge R930 4U rack server 4x Xeon E7-8890 v4 2.2GHz 24-core 3TB DDR4 24x 960GB SSD H330 X520/I350

SKU CH-TTB9-3BJNN

A 4U rack server with four 24-core Xeon processors at 2.2 GHz, 3 TB of DDR4 memory, twenty-four 960 GB SATA SSDs on an H330 controller, and quad-port 1 GbE plus 10 Gb SFP+ networking

  • Rack Height4U
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011
  • Number of CPU Cores24-Core Processor
  • # of Processors Installed4
  • 96 cores across 4 Xeon E7-8890 v4 CPUs handle heavy compute
  • 3 TB DDR4-2400 ECC memory supports large in-memory workloads
  • 24 × 960 GB SATA SSDs on PERC H330 deliver fast storage capacity
  • Dual 10 GbE SFP+ plus dual 1 GbE ports via X520/I350
  • Four 1100 W 80+ Platinum PSUs provide redundant power

Quad-socket Xeon server

The Dell PowerEdge R930 is a 4U rack server built around four Intel Xeon E7-8890 v4 processors, each running at 2.2 GHz with 24 cores. It ships with 3 TB of DDR4 registered ECC memory installed across 96 slots, and the platform scales to a maximum of 12 TB for large in-memory workloads.

Storage and networking inside

Twenty-four 2.5-inch SATA SSDs of 960 GB each are managed by a PERC H330 controller supporting RAID 0, 1, 5, 10 and 50. A quad-port daughter card adds two 1 GbE and two 10 Gb SFP+ connections, while iDRAC 8 Enterprise provides remote management. Four 1100 W platinum power supplies and sliding rails are included.

For memory-heavy consolidation

This system suits organisations running SAP HANA, Oracle, SQL Server or dense virtualisation where maximum core count and memory capacity in a single 4U chassis are priorities. Buyers who need GPU acceleration, front-accessible NVMe bays beyond the eight supported, or a smaller rack footprint should evaluate alternative platforms.

Highlights

  • 96 cores across 4 Xeon E7-8890 v4 CPUs handle heavy compute
  • 3 TB DDR4-2400 ECC memory supports large in-memory workloads
  • 24 × 960 GB SATA SSDs on PERC H330 deliver fast storage capacity
  • Dual 10 GbE SFP+ plus dual 1 GbE ports via X520/I350
  • Four 1100 W 80+ Platinum PSUs provide redundant power

Specifications

BrandDELL
SeriesPowerEdge R930
Rack Height4U
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011
Number of CPU Cores24-Core Processor
# of Processors Installed4
MAX Processors4
ChipsetIntel C602J
Installed Memory Size3TB
Memory TypeDDR4
Max Memory Capacity12TB
Number of Memory Slots96
Storage ControllerDell Perc H330 Controller
HDD InterfaceSATA
SSD (Installed)24 x 960GB SATA SSD
Raid LevelRAID 0/1/5/10/50
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much memory can the R930 scale to before I hit the ceiling?

The system supports up to 12TB of DDR4 across 96 DIMM slots.

What are the power and cooling implications of running four 1100W platinum supplies continuously?

Four 1100W 80+ Platinum PSUs provide redundant power for the 96-core configuration.

Which rails and bezel are included so the server mounts in my rack immediately?

Ready Rails and the front bezel ship with the unit for direct 4U rack installation.
