Silver 2U rack server chassis with twelve front drive bays

DELL

DELL PowerEdge R730XD 2U rack server E5-2650 v3 10C 2.3GHz 64GB DDR4 3x 2TB SAS H730

SKU CH-GAAN-MPCJW

2U rack server with a 10-core 2.3 GHz Xeon processor, 64 GB DDR4 memory, three 2 TB SAS drives and an H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610
  • 12 hot-plug 3.5" drive bays for high-density storage
  • Dual 750W redundant power supplies keep the server running
  • H730 12Gbps RAID controller supports RAID 0/1/5/6/10/50/60
  • Xeon E5-2650 v3 10-core 2.3GHz CPU with 20 threads
  • 64GB DDR4 memory in 24 DIMM slots up to 2400MT/s

Purpose-built storage server

The Dell PowerEdge R730XD is a 2U rack system designed for dense internal storage. It ships with a single Intel Xeon E5-2650 v3 processor, ten cores at 2.3 GHz, 64 GB of DDR4 memory, and three 2 TB 7.2K SAS drives behind an H730 RAID controller with 1 GB cache. Dual 750 W redundant power supplies and twelve hot-plug 3.5-inch bays complete the chassis.

Fit and alternatives

This server suits teams that need high-capacity SAS or SATA arrays with hardware RAID 0, 1, 5, 6, 10, 50 or 60 in a compact 2U form factor. It also fits workloads that can run within 64 GB of installed memory and a single CPU socket. Buyers who require more than twelve drive bays, a second processor from day one, or memory beyond the 64 GB already populated should evaluate larger platforms.

Deciding specification

The twelve 3.5-inch hot-plug bays paired with the H730 controller define the storage ceiling: up to 52 TB raw capacity using SAS or SATA drives. If your dataset fits within that limit and the RAID levels offered cover your redundancy needs, the R730XD matches the requirement; if you need more bays or a different controller feature set, this chassis will not scale far enough.

Highlights

  • 12 hot-plug 3.5" drive bays for high-density storage
  • Dual 750W redundant power supplies keep the server running
  • H730 12Gbps RAID controller supports RAID 0/1/5/6/10/50/60
  • Xeon E5-2650 v3 10-core 2.3GHz CPU with 20 threads
  • 64GB DDR4 memory in 24 DIMM slots up to 2400MT/s

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity64GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What rack space and mounting hardware are required to install this 2U server?

The server occupies 2U of rack height and needs a standard rack enclosure with matching mounting rails for the R730XD chassis.

Can the existing 1GbE daughter card stay in place if I add a 10GbE network daughter card later?

The system supports one network daughter card at a time; installing a 10GbE card replaces the factory 4-port 1GbE card.

How do I confirm the H730 controller sees all three 2TB SAS drives after first boot?

Open the H730 BIOS utility (Ctrl+R) or iDRAC8 storage view; both should list three 2TB 7.2K SAS drives in a healthy state.
