Silver 2U rack server with twelve 3.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730XD 2U rack server 2× E5-2650 v3 10-core 2.3 GHz 64 GB DDR4 3× 1 TB SATA H330

SKU CH-FNR0-TJV4X

2U rack server with dual 10-core Xeon CPUs at 2.3 GHz, 64 GB DDR4, three 1 TB SATA drives and an H330 RAID controller supporting twelve 3.5-inch hot-plug bays

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeDual Intel Xeon
  • MAX Processors2
  • ChipsetIntel C610
  • Dual Xeon processors deliver 40 threads for parallel workloads
  • 64 GB DDR4 memory supports virtualization and databases
  • Twelve 3.5″ hot-plug bays allow up to 52 TB raw storage
  • H330 RAID controller provides RAID 0/1/5/10/50/60 redundancy
  • Redundant 750 W power supplies maintain uptime during failures

2U rack server with dual Xeon processors

The Dell PowerEdge R730XD is a 2U rack server equipped with two Intel Xeon E5-2650 v3 ten-core processors running at 2.3 GHz. It ships with 64 GB of DDR4 memory installed across 24 DIMM slots. The system targets organisations that need dense compute and storage in a standard rack footprint.

Hot-plug drive bays and redundant power

Twelve 3.5-inch hot-plug bays accept SAS or SATA drives, and three 1 TB 7.2K SATA drives are included. A Dell PERC H330 RAID controller supports RAID 0, 1, 5, 10, 50 and 60. Dual 750 W hot-swap power supplies provide redundancy, while a DVD-ROM drive handles legacy media.

Memory ceiling and PCIe 3.0 expansion

The installed 64 GB matches the processor-limited maximum of 64 GB, though the chipset supports up to 1536 GB with higher-capacity DIMMs. Six PCIe 3.0 slots plus a dedicated RAID slot allow additional networking or acceleration cards. Remote management is handled by iDRAC8 with Lifecycle Controller.

Highlights

  • Dual Xeon processors deliver 40 threads for parallel workloads
  • 64 GB DDR4 memory supports virtualization and databases
  • Twelve 3.5″ hot-plug bays allow up to 52 TB raw storage
  • H330 RAID controller provides RAID 0/1/5/10/50/60 redundancy
  • Redundant 750 W power supplies maintain uptime during failures

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730XD
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeDual Intel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity64GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H330 Controller
HDD InterfaceSATA
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50/60
Max HDD Capacity52TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What RAID levels does the H330 controller support?

The H330 controller supports RAID 0, 1, 5, 10, 50 and 60 across the installed drives.

How many 3.5-inch drive bays does the R730XD chassis provide?

The 2U chassis holds up to twelve hot-plug 3.5-inch SAS or SATA drives.

How do I install additional memory in the 24 DIMM slots?

Populate the twelve slots per processor in matched pairs following the silkscreen sequence; the common error is leaving gaps between channels.
