Black rectangular Dell ALT-1203 power adapter with 5.5mm barrel connector and short cable

Dell ALT-1203 12V 3A 36W Power Adapter 5.5mmx2.5mm

SKU CH-3YR1-SMDG0

Delivers 36 W of 12 V DC power from 100–240 V AC with a 5.5 mm × 2.5 mm barrel plug and built-in overload, over-voltage and short-circuit protection

  • Type9 V
  • Changer TypeUSB C Charger
  • ColorBlack
  • Cable Length5 in.
  • Specifications36 watts, 12 volts_of_direct_current, 3 amps, 110 volts_of_a
  • Connector ABarrel Connector
  • Delivers stable 12 V DC at up to 3 A for reliable device operation
  • Accepts 100-240 V AC input for worldwide use without a voltage converter
  • Includes 5.5 mm × 2.5 mm barrel plug compatible with 5.5 mm × 2.1 mm sockets
  • Built-in overload, over-voltage, over-current, over-temperature and short-circuit protection safeguards connected equipment
  • Supplied with screw-terminal DC female connector for wiring devices lacking a barrel jack

Dell ALT-1203 36W adapter

The Dell ALT-1203 delivers 12 V at 3 A for 36 W maximum output. It suits LED strips, plant grow lights, digital picture frames, monitors, cameras and routers that draw up to 3 A. The unit accepts 100-240 V AC at 50/60 Hz for worldwide mains use.

Barrel connector with female terminal

A 5.5 mm x 2.5 mm male barrel plug fits devices with 5.5 mm x 2.1 mm sockets as well. Polarity is centre-positive, barrel-negative. The included screw-terminal female connector lets you attach bare wires for hardware lacking a DC jack. Flame-retardant casing and 20 AWG copper cable resist heat and physical stress.

3 A current ceiling

Output stops at 3 A, so any load above 3000 mA will not operate. Built-in overload, over-voltage, over-current, over-temperature and short-circuit protection shut the adapter down before damage occurs. The maker advises running at no more than 80 % of the 36 W rating for longevity. Operating range spans -20 °C to 60 °C with 0-95 % non-condensing humidity.

Highlights

  • Delivers stable 12 V DC at up to 3 A for reliable device operation
  • Accepts 100-240 V AC input for worldwide use without a voltage converter
  • Includes 5.5 mm × 2.5 mm barrel plug compatible with 5.5 mm × 2.1 mm sockets
  • Built-in overload, over-voltage, over-current, over-temperature and short-circuit protection safeguards connected equipment
  • Supplied with screw-terminal DC female connector for wiring devices lacking a barrel jack

Specifications

BrandDell
SeriesALT-1203
ModelALT-1203
Part NumberAL1203-WH
Type9 V
Changer TypeUSB C Charger
ColorBlack
Cable Length5 in.
Specifications36 watts, 12 volts_of_direct_current, 3 amps, 110 volts_of_alternating_current, Barrel Connector, 50/60Hz, type_a_2pin_na, LED Strip Light, Plant Grow Light, Digital Picture Frame, Monitor, Camera, Router, ALT-1203
Connector ABarrel Connector
Connector BBarrel Connector
Cable Jakcet TypePlastic
Connector StyleMale
FeaturesLED Strip Light, Plant Grow Light, Digital Picture Frame, Monitor, Camera, Router, Barrel Connector, AC, 36 watts
Dimensions14.33in W x 12.83in H x 9.06in D
Weight100 grams
Package Quantity1
Package Contents1
Disclaimernot_applicable

Questions about this item

What output voltage and current does the 5.5 mm × 2.5 mm barrel connector deliver?

The adapter supplies 12 V DC at up to 3 A, for a maximum of 36 W.

What are the physical dimensions and weight of the unit?

It measures 14.33 in wide, 12.83 in high and 9.06 in deep, and weighs 150 g.

How do you attach the included female DC connector to bare wires?

Loosen the terminal screws, insert the stripped wire ends, tighten the screws, then plug the connector into the adapter’s barrel output.
