Round 30 mm amber LED pilot light with chrome zinc die-cast body and Fresnel plastic lens

Dayton

Dayton 30G410 Pilot Light LED 24V 30mm Chrome Amber

SKU CH-V0AC-Q44FS

A 30 mm amber LED pilot light for 24 V AC/DC panels, with a chrome zinc die-cast body, IP65 and NEMA 13, 4 ratings

  • 24 V AC/DC operation suits low-voltage control panels
  • Amber LED gives clear status indication at a glance
  • 30 mm chrome bezel fits standard panel cut-outs
  • IP65 and NEMA 4/13 ratings protect against dust and water jets
  • CE and cULus markings confirm compliance with safety standards

30 mm amber pilot light

The Dayton 30G410 is a 30 mm round panel indicator with an amber LED lamp module. It operates on 24 V AC or DC and mounts in a standard 30 mm cut-out with a pressure-plate terminal connection. The chrome zinc die-cast body carries an IP65 rating and NEMA 13 and 4 ratings for industrial environments. A Fresnel plastic lens and the light module are included in the package.

Suited for 24 V control panels

This indicator suits panels that need a compact amber status light at 24 V AC/DC with a 30 mm mounting footprint. Builders who require a different voltage, a different lens colour or a larger cut-out size should look at alternative pilot lights. Applications needing a replaceable lamp should also consider other models because the lamp module is integrated and replacement lamps are not available.

Steady illumination under continuous duty

The LED lamp module delivers constant amber output for the duration of the 24 V supply without a warm-up period. The IP65 and NEMA 13/4 enclosure protects the internal electronics from dust and water jets during prolonged operation. The pressure-plate terminals maintain a secure connection under vibration, so the light remains reliable over extended production runs.

Highlights

  • 24 V AC/DC operation suits low-voltage control panels
  • Amber LED gives clear status indication at a glance
  • 30 mm chrome bezel fits standard panel cut-outs
  • IP65 and NEMA 4/13 ratings protect against dust and water jets
  • CE and cULus markings confirm compliance with safety standards

Specifications

BrandDAYTON

Questions about this item

What panel cut-out diameter is needed for the 30 mm pilot light?

The unit is built for a 30 mm mounting hole, so prepare a 30 mm cut-out in the panel.

Will the 24 V AC/DC LED work on a legacy 24 V DC control circuit?

Yes, the lamp module accepts both 24 V AC and 24 V DC supplies.

How can I confirm the IP65 seal is effective after installation?

Inspect the gasket seating and verify the pressure-plate terminals are tight; the NEMA 13 and IP65 ratings apply only when the lens and body are fully secured.
