Silver metal 2U rack module, 3.41 by 17.05 by 18.31 inches, 60.63 lbs

CyberPower

CyberPower BP48VL2U02 48 VDC 70 A 8×12 V/7 Ah ups replacement battery

SKU CH-YD75-EH8R4 MPN BP48VL2U02

Eight 12 V 7 Ah sealed lead-acid cells deliver 48 VDC at 70 A with hot-swap and daisy-chain expansion in a 2U rack tower

  • TypeBattery
  • CompatibilityModels: OL3KRM UPS Models: OL3KRM
  • SpecificationsGeneral Amperage: 70 A DC Voltage: 48 VDC Battery Battery Qu
  • Dimensions3.41'' x 17.05'' x 18.31''
  • Weight60.63 lbs.
  • 48 VDC output powers compatible UPS units
  • 70 A amperage delivers high-current backup capacity
  • Eight 12 V 7 Ah sealed lead-acid batteries provide extended runtime
  • Hot-swappable design allows battery replacement without downtime
  • Typical recharge reaches 90 % in 4 hours

Extended Battery Module for OL3KRM UPS

The CyberPower BP48VL2U02 is a 48 VDC extended battery module designed for the OL3KRM uninterruptible power supply. It contains eight sealed lead-acid batteries rated at 12 V / 7 Ah each and delivers a 70 A output. The unit fits a 2U rack or tower form factor and includes mounting hardware.

Replaces internal battery set when runtime must

This module replaces the standard internal battery configuration of the OL3KRM and adds hot-swappable capacity without shutting down the load. A built-in charger supports a typical recharge from zero to ninety percent in four hours. Daisy-chain expansion is available for further runtime scaling using the same cartridge type.

Suits IT managers extending backup time on OL3KRM

Buyers who need longer runtime for critical rack-mounted equipment will benefit from the hot-swap design and smart battery management. Users whose UPS model is not the OL3KRM or who require a different voltage platform should look at other compatible battery modules.

Highlights

  • 48 VDC output powers compatible UPS units
  • 70 A amperage delivers high-current backup capacity
  • Eight 12 V 7 Ah sealed lead-acid batteries provide extended runtime
  • Hot-swappable design allows battery replacement without downtime
  • Typical recharge reaches 90 % in 4 hours

Specifications

BrandCyberPower
ModelBP48VL2U02
TypeBattery
CompatibilityModels: OL3KRM
UPS Models: OL3KRM
SpecificationsGeneral
Amperage: 70 A
DC Voltage: 48 VDC
Battery
Battery Quantity: 8
Battery Size: 12 V / 7 Ah
Battery Type: Sealed Lead-Acid Battery
Built-in Charger: Yes
Expansion Ready (Daisy-Chain): Yes
Replacement Battery Cartridge: RB1270X4L
Replacement Battery Cartridge Quantity: 2
Typical Recharge Time: 4 Hours (0% to 90% charged)
User Replaceable Battery: Yes
Input
Input Plug Type: NEMA 5-15P
Input Voltage Range: 100 VAC - 125 VAC
Nominal Input Voltage: 120 VAC
Physical
Color: Silver
Material of Construction: Metal
Mounting Hardware: Yes
Rack Height: 2U
Dimensions3.41'' x 17.05'' x 18.31''
Weight60.63 lbs.
Shipping weight31.30 kg
Package size565 × 559 × 229 mm

Questions about this item

Will the 3.41'' x 17.05'' x 18.31'' module fit in a standard 2U rack slot?

Yes, the unit is a 2U rack/tower form factor measuring 3.41 inches high, 17.05 inches wide and 18.31 inches deep, so it occupies a standard 2U space.

How do I install the BP48VL2U02 and what step is often missed?

Mount the module using the included hardware, connect the daisy-chain cable to the UPS, then press the battery breaker on the rear panel to energise the circuit — skipping the breaker leaves the pack offline.

Which replacement cartridge does the BP48VL2U02 use and how many are needed?

It uses two RB1270X4L cartridges, each containing four 12 V / 7 Ah sealed lead-acid cells, for a total of eight user-replaceable batteries.
