White vandal-resistant dome camera with zoom lens, three-axis mount, dual power input

CNB

CNB VBT-24Z10F Vandal Dome Zoom Camera 10x Dual Power ICR

SKU CH-YQSA-CFP9D

Vandal-resistant dome camera with 10x optical zoom, 500 TV lines resolution, and dual 24VAC/12VDC power

  • 10× optical zoom captures distant detail
  • 500 TV lines deliver sharp analogue footage
  • 06 lux minimum illumination enables low-light recording
  • 100× combined zoom extends reach further
  • 24 VAC / 12 VDC dual voltage simplifies power options

CNB VBT-24Z10F vandal dome

This CNB VBT-24Z10F is a vandal-resistant dome camera built for analog CCTV systems. It delivers 500 TV lines of resolution through a 1/4 inch high-sensitivity CCD sensor. The housing withstands physical tampering while the 3-axis movement allows flexible lens positioning. Installers can power it from either 24VAC or 12VDC sources.

Upgrade from fixed analog cameras

The 10x optical zoom replaces fixed-lens units when the field of view must change after installation. Digital slow shutter down to 128x field extends low-light recording without extra lighting. RS-485 Pelco-D control lets operators adjust zoom and focus remotely. The jump is worth it when scenes need variable magnification or covert evidence capture.

Sustained operation behaviour

Dual voltage input keeps the camera running if one supply fluctuates during long shifts. The ICR day/night switch and 0.06 lux minimum illumination maintain usable images through dusk and dawn cycles. SDNR reduces noise during extended digital slow shutter exposures. Extra video out port simplifies on-site focus checks without interrupting the main feed.

Highlights

  • 10× optical zoom captures distant detail
  • 500 TV lines deliver sharp analogue footage
  • 06 lux minimum illumination enables low-light recording
  • 100× combined zoom extends reach further
  • 24 VAC / 12 VDC dual voltage simplifies power options

Specifications

BrandCNB
ModelVBT-24Z10F

Questions about this item

What voltage options does the VBT-24Z10F accept for power?

The camera operates on 24VAC or 12VDC dual voltage, so you can connect it to either supply without extra converters.

How do you adjust the lens position during installation?

Use the 3-axis movement to rotate and tilt the lens freely, then secure it; the common mistake is tightening the housing before the view is centred.

What does the RS-485 Pelco-D interface control on this camera?

It lets a compatible DVR or keyboard drive the 10x optical zoom, focus, iris and OSD settings remotely over the same cable run.
