CAFELE G5015M12D1 50 mm 12 V case fan

50 mm 12 V case fan for compact builds

The CAFELE G5015M12D1 is a 50 mm square frame fan that runs on 12 V DC and draws 0.2 A. Its 15 mm thickness suits tight clearance areas such as small-form-factor cases or car audio enclosures. The four-wire lead supports temperature-controlled speed regulation. Buyers needing quiet airflow in confined spaces will find this model appropriate.

Verify 12 V header and 50 mm mounting holes

Confirm your motherboard or controller provides a 12 V four-pin header capable of supplying at least 0.2 A. Measure the mounting pattern to ensure 50 mm centre-to-centre screw holes align with your chassis or heatsink. The 15 mm depth must fit within available clearance without contacting cables or other components. No adapter or converter is included in the package.

50×50×15 mm frame with four-wire PWM control

The plastic frame measures 50 mm by 50 mm by 15 mm and carries a 100 % factory test stamp. Four-wire PWM connection allows the fan to adjust speed automatically based on temperature input. Standard 50 mm mounting holes accept common M3 screws for secure installation. The lightweight construction adds minimal mass to portable or vibration-sensitive setups.
