Rectangular metal fiber patch panel with six blue LC quad adapters visible on the front face

Cable Matters 24 Fibers LC to LC OS2 Single Mode Fiber Patch Panel

SKU CH-2CF9-GWK0M

A 24-fibre LC-to-LC OS2 single-mode patch panel with six quad adapters for 1U rack mounting

  • TypeFiber Optic
  • Connector NumberLC
  • Supports 24 fibers for high-density network expansion
  • OS2 single-mode compatibility enables 10Gbps fiber connections
  • Six LC UPC quad adapters provide 24 LC ports
  • LGX compatible design fits standard 1U rack systems
  • Tool-less snap-in screws simplify installation in 1.5mm steel housing

24-Fiber LC Patch Panel

The Cable Matters 24 Fibers LC to LC OS2 Single Mode Fiber Patch Panel provides a rack-mountable interconnect point for single-mode fiber networks. It is designed for installers who need to terminate up to 24 fibers in a standard LGX-compatible footprint.

OS2 Single-Mode Compatibility

The panel accepts OS2 fiber optic cables and supports network speeds up to 10Gbps. Its six built-in LC UPC quad adapters deliver 24 LC connections, making OS2 single-mode support the specification that determines whether this panel matches the installed cabling.

Passive Thermal Profile

As a passive component with no active electronics, the panel generates no heat and produces no audible noise. It draws zero power and requires no cooling consideration, while the 1.5mm SPCC steel chassis provides mechanical protection within a 1U rack space.

Highlights

  • Supports 24 fibers for high-density network expansion
  • OS2 single-mode compatibility enables 10Gbps fiber connections
  • Six LC UPC quad adapters provide 24 LC ports
  • LGX compatible design fits standard 1U rack systems
  • Tool-less snap-in screws simplify installation in 1.5mm steel housing

Specifications

BrandCable Matters
Model24 Fibers LC to LC OS2 Single Mode Fiber Patch Panel
TypeFiber Optic
Connector NumberLC

Questions about this item

What does the 10Gbps rating mean when the patch panel is installed in a live rack?

The panel's LC adapters are specified for OS2 single-mode fibre at up to 10Gbps, so the 10GBASE link budget is maintained through the cross-connect.

Which interface standard do the built-in adapters follow, and what does it limit?

Six LC UPC quad adapters provide 24 LC ports; the UPC polish limits return loss to typical single-mode values for OS2 links.

What physical space and mounting does the panel need to fit in a standard rack?

It measures 5.12 x 1.24 x 1.36 inches (130 x 31.6 x 34.5 mm), mounts in a 1U 19-inch LGX slot and uses snap-in screws for toolless installation.
