Flat 600mm riser cable with low-profile X1 plug and X4 socket, foam-backed female end

BUCIER

BUCIER UEX103 600mm PCIe 3.0 X1 to X4 Riser Cable

SKU CH-TWHJ-AMYAC

Extends a covered PCIe X1 slot 600mm and converts it to X4 for add-in cards at up to 1GB/s

  • Extends a blocked PCIe x1 slot by 600mm and converts it to x4
  • Low-profile 6mm male end fits under most graphics cards
  • Supports PCIe 3.0 x1 bandwidth up to ~1GB/s and PCIe 2.0 x1 at ~0.5GB/s
  • Flexible round cable twists freely and insulating foam base allows adhesive mounting
  • Delivers up to 30W at 12V for compatible expansion cards

Extends a covered PCIe X1 slot 600mm

The BUCIER UEX103 is a 600mm riser cable that brings a motherboard PCIe X1 slot out from under a graphics card and converts it to a physical X4 connector. It targets builders whose X1 slot is blocked and who need to install an expansion card such as a Wi-Fi, M.2, FireWire, USB or sound card. The male end is only 6mm high, so it fits in the narrow gap between motherboard and GPU in most cases.

Flexible round cable with insulated base

The 600mm round wire can be twisted to any angle, letting the female X4 connector be positioned virtually anywhere inside the chassis. An insulating foam layer on the bottom surface accepts self-adhesive tape (not included) for secure mounting at any orientation. The cable operates at 12 Voltage and delivers up to 30W of output power to the attached card.

Check slot version and card power needs

Bandwidth is limited to PCIe 3.0 X1 at roughly 1GB/s; if the slot is PCIe 2.0 the link drops to about .5GB/s. Verify that the expansion card you plan to use does not require more than 30W and that it functions correctly at X1 electrical speeds. If the system crashes or blue-screens after installation, re-seat the riser and ensure all connections are secure.

Highlights

  • Extends a blocked PCIe x1 slot by 600mm and converts it to x4
  • Low-profile 6mm male end fits under most graphics cards
  • Supports PCIe 3.0 x1 bandwidth up to ~1GB/s and PCIe 2.0 x1 at ~0.5GB/s
  • Flexible round cable twists freely and insulating foam base allows adhesive mounting
  • Delivers up to 30W at 12V for compatible expansion cards

Specifications

BrandGLOTRENDS
ModelUEX103

Questions about this item

Does the 600mm cable need any periodic maintenance or replacement?

The riser is a passive cable with no moving parts, so no scheduled maintenance or replacement is required.

What limits performance first when the card runs continuously at full load?

Bandwidth caps at PCIe 3.0 X1 (~1GB/s); if the slot is PCIe 2.0 the ceiling drops to ~.5GB/s.

How much heat or power does the riser add when the system runs all day?

It draws up to 30W at 12 Voltage and adds negligible heat beyond the attached card.
