Black Mini SAS SFF-8087 male to four right-angle SATA female connectors, 3.3 ft

BUCIER

BUCIER Mini SAS SFF-8087 to 4 SATA 90° Breakout Cable 3.3FT

SKU CH-AC7A-V11BW

Connects a SAS controller to four SATA drives using a 3.3 ft SFF-8087 breakout cable with 90-degree right-angle connectors for tight spaces

  • TypeMini-SAS Cables
  • ColorBlack+blue
  • Length3.3
  • Speed6 gigabits_per_second
  • ConductorCopper
  • Featuressff-8087 to sata right angle 90 degree
  • Connects one controller to four drives
  • Mini SAS SFF-8087 host with locking latch
  • Four right-angle SATA connectors ease tight builds
  • 30 AWG copper conductors support 6 Gbps per drive
  • 3 ft length fits standard chassis routing

Internal SAS-to-SATA breakout cable

This BUCIER cable converts one internal Mini SAS SFF-8087 36-pin male connector into four SATA 7-pin female right-angle connectors. The 3.3 ft length uses 30 AWG copper conductors rated for 6 Gb/s per drive and both ends feature locking latches. It is designed to link a SAS RAID controller or HBA directly to up to four SATA hard drives or SSDs.

Builders connecting a controller to discrete drives

Suits anyone wiring a SAS HBA or RAID card to individual SATA drives inside a chassis where the 90-degree SATA plugs ease routing. Not for installations that require straight SATA connectors, longer reach than 3.3 ft, or a Mini SAS SFF-8087 female port on the host side. Also unsuitable if the target device expects a Mini SAS receptacle rather than four separate SATA ports.

Host connector is SFF-8087 36-pin male

The cable only works when the controller or motherboard presents an internal SFF-8087 36-pin male port; plugging the Mini SAS end into a backplane or any other connector type will not function. Verify that single port type before purchase.

Highlights

  • Connects one controller to four drives
  • Mini SAS SFF-8087 host with locking latch
  • Four right-angle SATA connectors ease tight builds
  • 30 AWG copper conductors support 6 Gbps per drive
  • 3 ft length fits standard chassis routing

Specifications

BrandADCAUDX
ModelMini SAS-0015
TypeMini-SAS Cables
ColorBlack+blue
Length3.3
Speed6 gigabits_per_second
ConductorCopper
Featuressff-8087 to sata right angle 90 degree

Questions about this item

What comes in the box and is anything else needed to connect four drives?

The package includes one 3.3FT Mini SAS SFF-8087 male to four SATA 7-pin female right-angle cables. The SFF-8087 end plugs into a SAS HBA or RAID controller; each SATA end connects directly to a drive or backplane. No extra adapters are required for the four SATA targets.

The cable is described as 6 Gbps per drive; does the 12 Gbps host link limit drive choice?

The SFF-8087 host connector supports 12 Gbps aggregate bandwidth, while each of the four SATA lanes runs at 6 Gbps. Any 6 Gbps SATA SSD or HDD will operate at its rated speed; the 12 Gbps host capability simply provides headroom for four simultaneous 6 Gbps streams.

What does the 90-degree SATA connector orientation mean inside a typical case?

Each SATA plug angles 90 degrees forward from the cable, allowing the connector to sit flat against a drive or backplane. This reduces strain in tight drive cages and keeps the 30 AWG cable routed cleanly alongside the chassis without sharp bends.
