Blue 60A 250V IEC309 straight blade plug with watertight nylon body

Bryant

Bryant BRY460R9W 60A 250V 3P4W IEC309 straight blade plug

SKU CH-TGT8-C21M5

Watertight IEC 309 pin-and-sleeve plug rated 60 A, 250 V AC, three-pole four-wire for three-phase power

  • ColorBlue
  • Watertight IEC 309 construction protects against moisture ingress
  • 60 A 250 V AC rating supports heavy-duty three-phase loads
  • 5 hp motor capacity handles demanding industrial equipment
  • Blue nylon housing provides visible identification and impact resistance
  • UL 498 listed for verified electrical safety compliance

Bryant BRY460R9W 60A 250V 3P4W IEC309 straight

This Bryant receptacle is a 60 A, 250 V AC, three-phase, four-wire pin-and-sleeve device rated for 5 hp motor loads. The blue nylon body meets IEC 309-1 and 309-2 as well as UL 498 standards. It is intended for industrial power connections where a watertight, switch-rated interface is not required. Buyers needing a lower amperage or single-phase configuration will need a different device.

Sustained load behaviour

The receptacle carries its full 60 A rating continuously when mated with a compatible plug and wired to a suitable 240 V AC three-phase supply. The nylon housing resists heat and impact during prolonged motor operation at 5 hp. No switch or power-indication features are present, so external disconnect and monitoring must be provided by the installer. It is not suited for applications that demand integral switching or visual status feedback.

IEC 309 interface limits

The pin-and-sleeve geometry follows IEC 309-1 and 309-2, ensuring mechanical interchange with other compliant 60 A, 250 V, 3P4W connectors. The grounding style is IEC and the device is not switch-rated, so it cannot serve as a load-break disconnect. Voltage is limited to 250 V AC and the hp rating is fixed at 5 hp; higher voltages or horsepower require a different IEC 309 form factor. Compliance with UL 498 does not extend the electrical ratings beyond those stated.

Highlights

  • Watertight IEC 309 construction protects against moisture ingress
  • 60 A 250 V AC rating supports heavy-duty three-phase loads
  • 5 hp motor capacity handles demanding industrial equipment
  • Blue nylon housing provides visible identification and impact resistance
  • UL 498 listed for verified electrical safety compliance

Specifications

BrandBRYANT
ColorBlue

Questions about this item

How much heat does the 60 A 250 V receptacle generate under continuous three-phase load?

The nylon body and IEC 309 pin-and-sleeve contacts are rated for 60 A at 250 V AC; normal operation stays within the thermal limits defined by UL 498 and IEC 309-1/2.

What wiring and circuit protection must already be in place for this 3-pole 4-wire plug?

A three-phase 240 V AC supply with four conductors (three hot, one ground), a 60 A branch circuit breaker, and conduit or cable sized for 60 A at 250 V are required.

Will this blue IEC 309 receptacle mate with older 60 A 250 V pin-and-sleeve inlets on existing equipment?

Yes — compliance with IEC 309-1 and 309-2 ensures mechanical and electrical interchangeability with any 60 A 250 V 3P4W inlet built to the same standards.
