Grey vandal-proof IR dome camera with 24 infrared LEDs and 3.6mm lens

Bluecctv

Bluecctv bl-S6024-G 600TVL IR Dome Camera 3.6mm Grey

SKU CH-FDDT-4XV4B

Vandal-proof infrared dome camera with 600TVL resolution, 24 IR LEDs reaching 60ft, 3.6mm lens and BNC connection

  • Network CameraNo
  • Camera TypeDay Camera
  • TypeInfrared Camera
  • Connection TypeBNC
  • Sensor & Detector600TVL
  • 600 TVL resolution delivers clear analogue video detail
  • 24 infrared LEDs provide night vision up to 60 ft
  • 6 mm fixed lens offers a wide field of view
  • Vandal-resistant dome housing protects the camera from tampering
  • BNC connection ensures simple integration with existing DVR systems

600TVL IR Dome Camera for BNC Systems

The Bluecctv bl-S6024-G is an analogue infrared dome camera built for CCTV installations that use BNC cabling. It captures 600TVL resolution through a 1/3 HR CCD sensor and a fixed 3.6mm lens. The grey vandal-resistant housing suits indoor or outdoor mounting where a compact dome form factor is required.

Passive Cooling with 12V DC Supply

The unit draws power from a 12V DC source and relies on natural convection through the 94mm by 69mm aluminium housing for thermal management. No internal fan is present, so acoustic output is effectively zero during operation. Twenty-four infrared LEDs activate automatically in low light to provide illumination without adding audible noise.

60ft IR Range Determines Coverage

Twenty-four IR LEDs deliver a maximum night-vision distance of 60ft, which defines the effective monitoring radius after dark. If the target area exceeds this range, supplementary lighting or a camera with longer IR reach will be necessary. The fixed 3.6mm lens sets the field of view and cannot be adjusted on site.

Highlights

  • 600 TVL resolution delivers clear analogue video detail
  • 24 infrared LEDs provide night vision up to 60 ft
  • 6 mm fixed lens offers a wide field of view
  • Vandal-resistant dome housing protects the camera from tampering
  • BNC connection ensures simple integration with existing DVR systems

Specifications

BrandBluecctv
Modelbl-S6024-G
Network CameraNo
Camera TypeDay Camera
TypeInfrared Camera
Connection TypeBNC
Sensor & Detector600TVL

Questions about this item

How do I mount the 94 mm diameter dome and run the BNC cable without damaging the 3.6 mm lens?

Secure the base to a flat surface with the supplied screws, route the coaxial cable through the centre grommet, then attach the dome — avoid touching the lens surface during alignment.

When will the 24 IR LEDs need attention and what should I check?

Expect gradual output loss after several years; clean the LED window annually and verify 12 V supply stability if night range drops below 60 ft.

At what point does the 1/3 HR CCD hit its low-light limit during continuous night recording?

The sensor relies on the 24 IR LEDs for illumination up to 60 ft; beyond that distance or if LEDs degrade, image noise increases sharply.
