Orange Cat6 plenum cable reel 1000 ft solid copper UTP

Black Box Corporation

Black Box Corporation EYN867B-PB-1000 Cat6 550 MHz 23 AWG UTP solid copper network ethernet cable 1000 ft

SKU CH-P94R-TAJGN MPN EYN867B-PB-1000

Plenum-rated Cat6 bulk cable with 23 AWG solid copper conductors tested to 550 MHz for 1 Gbps runs, supplied in a 1000 ft pull box marked every two feet

  • TypeNetwork Ethernet Cables
  • Cat6
  • Connector ABare Wire
  • Connector BBare Wire
  • Length1000 ft.
  • ColorOrange
  • Tested to 550 MHz for 1 Gbps transmission headroom
  • 23 AWG solid copper conductors with cross-member for strength
  • Plenum-rated CMP jacket with FEP insulation meets fire codes
  • 1000 ft pull-box marked every two feet for easy measurement
  • Meets ANSI/TIA-568-C.2 and ISO/IEC 11801 Class E standards

Plenum-rated Cat6 bulk cable

Black Box EYN867B-PB-1000 is a 1000 ft Cat6 plenum-rated bulk cable with bare wire ends. It uses 23 AWG solid copper conductors in a 4-pair UTP construction with a cross-member for strength. The Violet CMP jacket and FEP insulation meet fire-safety requirements for in-wall and air-handling spaces. Installers pull and terminate to length on site.

Suited for structured cabling runs

This cable suits installers building permanent Cat6 links in plenum spaces who need 550 MHz tested performance and footage markers every two feet. It is not for buyers who need pre-terminated patch cords, shielded cable for noisy environments, outdoor or direct-burial rated jackets, or higher bandwidth categories such as Cat6a.

550 MHz tested transmission rate

The cable is tested to 550 MHz and 1 Gbps, providing headroom above the base Category 6 requirement. This frequency rating is the key figure that confirms the cable will support Gigabit Ethernet and high-bandwidth video across the full 1000 ft length when properly terminated.

Highlights

  • Tested to 550 MHz for 1 Gbps transmission headroom
  • 23 AWG solid copper conductors with cross-member for strength
  • Plenum-rated CMP jacket with FEP insulation meets fire codes
  • 1000 ft pull-box marked every two feet for easy measurement
  • Meets ANSI/TIA-568-C.2 and ISO/IEC 11801 Class E standards

Specifications

BrandBlack Box
ModelEYN867B-PB-1000
TypeNetwork Ethernet Cables
Cat6
Connector ABare Wire
Connector BBare Wire
Length1000 ft.
ColorOrange
ShieldedUnshielded
FeaturesPremium high-speed cabling intended for Cat6 plenum applications
Tested to 550 MHz/1 Gbps transmission rate
High-quality 23 AWG UTP 4-pair solid copper wire with cross-member for added strength
Plenum-rated Violet CMP flame-retardant PVC jacket with FEP insulation
Guaranteed to meet or exceed ANSI/TIA/EIA-568-C.2 Category 6 and ISO/IEC 11801 Class E requirements.
1000-ft. roll is marked in two-foot increments so you always know how much you have available
Shipping weight13.61 kg
Package size419 × 413 × 229 mm

Questions about this item

Does the pull-box contain connectors or tools, or just the bare cable?

The box contains a 1000 ft roll of bare 23 AWG UTP solid copper cable with no connectors or tools included.

Is the 550 MHz rating on this orange plenum cable the only version available?

This model is offered as a single 1000 ft orange plenum-rated reel; no other colours, lengths or jacket ratings are listed.

What does the 550 MHz test figure mean for actual Gigabit Ethernet runs?

The cable is tested to 550 MHz and rated for 1 Gbps transmission, meeting ANSI/TIA-568-C.2 Category 6 and ISO/IEC 11801 Class E requirements.
