Small white dome sensor unit with fixed lens and IR LEDs, compact cylindrical form, smooth matte finish

Axis Communications

Axis Communications F4105-LRE 02364-021 network camera

SKU CH-N1BK-92MF8 MPN 02364-021

Discreet mini dome sensor with built-in IR, 111-degree field of view, IP6K9K rating and 1080p at 60 fps

  • Network CameraYes
  • TypeDome Camera
  • Pan/TiltYes
  • Pan/Tilt/ZoomPan: ±180 degrees Tilt: 120 degrees Rotation: ±90 degrees
  • Sensor & DetectorCMOS
  • MAX Resolution1920 x 1080
  • Discreet 54 mm height fits tight spaces
  • 111 degree horizontal view covers wide areas
  • 60 fps at 1080p captures smooth motion
  • IP6K9K rating withstands harsh environments
  • Built-in IR illuminates scenes in darkness

Discreet dome sensor pack

The Axis F4105-LRE is a modular dome sensor unit supplied in a pack of eight. Each sensor measures 54 mm high with a 112 mm diameter and weighs 240 g. It is built for discreet indoor or outdoor surveillance where a low-profile rugged camera is required.

1080p at 60 fps specification

The single specification that decides fit is the maximum resolution of 1920 x 1080 at up to 60 frames per second. A 2.8 mm fixed lens with F1.6 aperture delivers a 111 degree horizontal field of view. Buyers who need higher resolution than 1080p or a varifocal lens cannot use this sensor.

Sustained operation with IR and IP6K9K

Built-in IR illumination supports low-light recording without external lighting. The IP6K9K rating protects the sensor against high-pressure, high-temperature wash-downs. Wide dynamic range maintains image balance in scenes with strong backlight. The unit has no on-board storage, no PoE and no audio support, so it relies on a separate main unit for power, recording and network connectivity.

Highlights

  • Discreet 54 mm height fits tight spaces
  • 111 degree horizontal view covers wide areas
  • 60 fps at 1080p captures smooth motion
  • IP6K9K rating withstands harsh environments
  • Built-in IR illuminates scenes in darkness

Specifications

BrandAXIS
SeriesF Series
ModelF4105-LRE
Part Number02364-021
Network CameraYes
TypeDome Camera
Pan/TiltYes
Pan/Tilt/ZoomPan: ±180 degrees
Tilt: 120 degrees
Rotation: ±90 degrees
Sensor & DetectorCMOS
MAX Resolution1920 x 1080
Frame RateUp to 60/50 fps (60/50 Hz) in 1080p and up to180/175 fps (60/50 Hz) in 720p
Lens Type2.8 mm, F1.6
DimensionHeight: 54 mm (2.1 in)
ø 112 mm (4.4 in) 55 mm (2.2 in)
Cable length: 116 mm (4.55 in)
Weight240 g (0.53 lb)
Shipping weight0.20 kg
Package size152 × 152 × 102 mm

Questions about this item

What frame rate will I actually see at 1080p in a live installation?

The sensor delivers up to 60 fps at 1920 x 1080 resolution, with 50 fps at 50 Hz power frequency.

How does the M12 lens mount limit my lens choices?

The unit ships with a fixed 2.8 mm F1.6 lens and accepts exchangeable M12 lenses for different focal lengths.

What clearance do I need above the ceiling tile for the dome?

The dome measures 54 mm high and 112 mm in diameter, with a 116 mm cable tail for the main unit connection.
