Grey HDMI audio extractor box with 90 degree connectors

avedio links Grey 4K@60Hz HDMI ARC Audio Extractor with Optical

SKU CH-TDKF-RDHBF

Extracts audio from HDMI sources to optical 5.1CH, L/R stereo or 3.5mm AUX outputs and supports ARC mode for TV audio return at 4K 60Hz

  • TypeGrey, HDMI
  • StyleGrey
  • ColorGrey 90 degree
  • Specificationsavedio links, HDMI, 22, 6
  • Thunderbolt 3HDMI
  • Connector AHDMI 22
  • Extracts audio from HDMI sources to optical 5.1CH, L/R stereo or 3.5mm AUX outputs
  • ARC mode sends TV audio to external speakers via HDMI OUT with CEC enabled
  • Three operating modes: pass-through, 2.1CH PCM on all outputs, or 5.1CH PCM on all outputs
  • Powered by USB-C 5V cable for reliable operation without display connection required
  • Aluminium connectors and 90-degree grey design for durable signal integrity

4K@60Hz HDMI ARC Audio Extractor

The avedio links Grey extractor pulls audio from an HDMI source and sends it to a display plus optical 5.1CH, stereo RCA or 3.5mm outputs. It also works in reverse, taking sound from a TV ARC port to external speakers. A USB-C 5V cable must be connected for power.

Upgrade from basic HDMI audio splitting

This unit replaces a simple HDMI splitter that only passes audio through the video cable. The jump is worth it when you need discrete optical 5.1CH or analogue stereo feeds for a soundbar, AV receiver or headphones while keeping the video path intact.

Handles 4K@60Hz video with multi-channel audio

The extractor passes 4K@60Hz video and supports PCM 2.1CH through all outputs or PCM 5.1CH through optical in OPT mode. Higher bitstream formats only produce sound on specific interfaces, so Dolby Digital Plus or DTS-HD streams will not play on every port.

Highlights

  • Extracts audio from HDMI sources to optical 5.1CH, L/R stereo or 3.5mm AUX outputs
  • ARC mode sends TV audio to external speakers via HDMI OUT with CEC enabled
  • Three operating modes: pass-through, 2.1CH PCM on all outputs, or 5.1CH PCM on all outputs
  • Powered by USB-C 5V cable for reliable operation without display connection required
  • Aluminium connectors and 90-degree grey design for durable signal integrity

Specifications

Brandavedio links
Seriesavedio links Grey
ModelGrey avedio links
Part Number4K60Hz ARC
TypeGrey, HDMI
StyleGrey
ColorGrey 90 degree
Specificationsavedio links, HDMI, 22, 6
Thunderbolt 3HDMI
Connector AHDMI 22
Audio6, HDMI
Connector PlatingAluminum
Cable Jakcet TypeAluminum
FeaturesHDMI, Grey, 22, 6
Package Contents1
Disclaimernot_applicable

Questions about this item

What HDMI port spacing does the 90 degree Grey housing need?

The 90 degree Grey housing uses an HDMI 22 connector layout, so allow enough rear clearance for the right-angle bend to sit flush against the source or display port.

Which DIP switch position and TV setting enable ARC extraction?

Set the DIP switch to TV mode, enable CEC on the TV, and connect the TV's HDMI ARC port to the extractor's HDMI OUT using an ARC-capable HDMI cable.

When will the USB-C 5V power cable need replacing?

Replace the USB-C 5V power cable if the extractor loses power intermittently or fails to start, since the unit requires that cable for every operating mode.
