AUBEAMTO
AUBEAMTO OZFD DisplayPort Splitter 1 in 2 Out 4K 144Hz Audio Extractor Black
Splits one DisplayPort signal to two monitors at up to 4K 144 Hz with a separate 3.5 mm audio output
- TypeDisplayPort Switchers
- ColorBlack
- Ports2
- AudioYes
- Specifications* Power Supply: 5V/2A *Video format: 3840x2160@144Hz *Using
- Input Connector1 X DisplayPort
- Connect two monitors from one DisplayPort output with 3840×2160 at 144 Hz
- Extend or mirror desktops on Windows via MST up to 4K@120 Hz
- Extract audio through a dedicated 3.5 mm port for separate speakers or headphones
- Works instantly on Windows, Mac and Linux with no driver installation
- Powers reliably from the included 5 V/2 A USB-C supply
Splitter for dual DisplayPort monitors
The AUBEAMTO OZFD is a DisplayPort switch that takes one DP input and drives two DP outputs simultaneously. It is intended for desktop or laptop users who need to mirror or extend a single source across two monitors without installing an additional graphics card.
4K 144 Hz maximum resolution on a single display
The splitter follows the DisplayPort 1.4 specification and delivers up to 3840x2160 at 144 Hz when only one monitor is active. In MST extended mode the ceiling drops to 4K at 120 Hz, and Mac or Linux systems are limited to mirror mode regardless of resolution.
External power and audio extraction included
A 5 V 2 A power adapter and a USB-C power cable are bundled so the unit can maintain signal integrity over cables up to 10 metres. The built-in 3.5 mm audio port extracts the audio stream for headphones or speakers, keeping sound synchronised with the video on both screens.
Highlights
- Connect two monitors from one DisplayPort output with 3840×2160 at 144 Hz
- Extend or mirror desktops on Windows via MST up to 4K@120 Hz
- Extract audio through a dedicated 3.5 mm port for separate speakers or headphones
- Works instantly on Windows, Mac and Linux with no driver installation
- Powers reliably from the included 5 V/2 A USB-C supply
Specifications
| Brand | AUBEAMTO |
|---|---|
| Series | OZFD |
| Model | OZFD |
| Type | DisplayPort Switchers |
| Color | Black |
| Ports | 2 |
| Audio | Yes |
| Specifications | * Power Supply: 5V/2A *Video format: 3840x2160@144Hz *Using cable instance: 10 meter DisplayPort cable * Length x Width x Height: 74 *74 *14 (mm) * Weight: 35g |
| Input Connector | 1 X DisplayPort |
| Output Connector | 2 X DisplayPort |
| Maximum Resolutions | 3840 x 2160 |
| Features | 1. 1 DP input and 2 DP output simultaneously; 2. DisplayPort 1.4 specification standard. 3. The highest video resolution is 3840x2160@144Hz. 4. Supports up to 3840x2160@120Hz for MST mode. 5. Transfer rates up to 32.4Gbps. 6. Can drive 10 meter DisplayPort cable. |
| Package Quantity | 1 |
| Package Contents | 1* DisplayPort Splitter, 1x Power Adapter, 1* USB to Type-C Power cable (5V/2A), 1*User Manual. |
Questions about this item
What does 3840x2160@144Hz mean when I connect two monitors?
In mirror mode both screens show the same image at 4K 144 Hz; in extended MST mode the maximum drops to 4K 120 Hz and only Windows supports it.
Which DisplayPort standard limits the bandwidth?
The splitter follows the DisplayPort 1.4 specification with a transfer rate up to 32.4 Gbps, capping resolution and refresh rate combinations.
What space and power does the unit need to sit on my desk?
The box measures 74 by 74 by 14 mm and weighs 35 g; it requires the included 5 V 2 A power adapter via the USB-C cable.
