Pair of small silver rack-mountable boxes with DisplayPort and RJ-45 ports

ATEN TECHNOLOGIES

ATEN TECHNOLOGIES VE901 DisplayPort HDBaseT extender

SKU CH-K3JY-MTZ0V MPN VE901

Extends a DisplayPort signal up to 229.66 ft over Category 6a twisted pair at 4096 x 2160 resolution

  • Extends 4K DisplayPort up to 229.66 ft
  • Single Cat6a cable carries video and control
  • Rack-mountable transmitter fits standard 1U spaces
  • Transmitter weighs only 1.12 lb for easy install
  • RoHS and WEEE certified for greener deployments

DisplayPort HDBaseT extender for 4K signals

The ATEN VE901 extends a single DisplayPort source up to 229.66 ft over Category 6a twisted-pair cabling. It supports a maximum video resolution of 4096 x 2160 and includes both a transmitter and a receiver in the package. Rack-mountable units suit professional AV installations that need long-distance 4K distribution.

HDBaseT distance and cable constraints

The 229.66 ft operating limit applies only when using Category 6a cable; lesser categories will reduce the reliable range. Two RJ-45 ports on each unit carry the video, audio and control signals together. The extender does not add compression latency beyond the HDBaseT-Lite specification.

Rack installation and common pitfalls

Each unit measures 1.18 in high, 3.43 in wide and 3.96 in deep, fitting standard rack shelves with the supplied hardware. The package provides two power adapters, one for each endpoint, so both sides need an AC outlet. Forgetting to power the receiver is the most frequent cause of a blank display.

Highlights

  • Extends 4K DisplayPort up to 229.66 ft
  • Single Cat6a cable carries video and control
  • Rack-mountable transmitter fits standard 1U spaces
  • Transmitter weighs only 1.12 lb for easy install
  • RoHS and WEEE certified for greener deployments

Specifications

BrandATEN TECHNOLOGIES
Shipping weight0.77 kg
Package size229 × 178 × 76 mm

Questions about this item

Should I choose the transmitter or the receiver for my source device?

The VE901T transmitter connects to your DisplayPort source; the VE901R receiver connects to the display. Both units are included in the package.

What does the 4096 x 2160 resolution mean for my 4K monitor?

It delivers full 4K DCI resolution at 60 Hz over a single Category 6a twisted-pair cable up to 229.66 ft.

How does the dual RJ-45 HDBaseT interface limit cable length?

The two RJ-45 ports pass HDBaseT-Lite signals over Category 6a cable, capping the run at 229.66 ft.
