White transparent 140 mm case fan with PWM control

ARCTIC

ARCTIC P14 PWM 140 mm case fan White/Transparent

SKU CH-YTGC-6YGFC

A 140 mm PWM case fan optimised for static pressure on heatsinks and radiators, running at 200–1700 RPM with 72.8 CFM airflow and 0.3 Sone noise

  • Optimised for static pressure suits heatsinks and radiators
  • PWM control from 200 to 1700 RPM keeps noise low
  • Neodymium magnet motor runs more efficiently than predecessors
  • Low coil temperature extends service life four times
  • 8 CFM airflow at 0.3 Sone delivers quiet performance

Pressure-optimised 140 mm fan

The ARCTIC P14 PWM is a 140 mm case fan built for high static pressure. Its blade geometry and motor are tuned to push air through dense heatsinks and radiators where resistance is high. The 4-pin PWM connector lets the motherboard vary speed from 200 to 1700 RPM. It suits builders who need focused airflow in restricted paths.

Upgrade from standard airflow fans

Typical case fans move air freely but stall against a radiator or thick fin stack. This model replaces those when the cooling path adds resistance and temperatures climb. The jump is worth it when a CPU cooler or liquid radiator cannot breathe with regular fans. It is not for builds that only need high volume flow through open mesh.

Sustained load behaviour

At 1700 RPM the fan delivers 72.8 CFM (123.76 m³/h) at 0.3 Sone. A neodymium-iron-boron magnet ring lowers coil temperature by roughly 10 °C, which the maker says quadruples service life. The motor therefore runs cooler and keeps its speed steady during long sessions. Buyers who need silence at idle but headroom under load will notice the difference.

Highlights

  • Optimised for static pressure suits heatsinks and radiators
  • PWM control from 200 to 1700 RPM keeps noise low
  • Neodymium magnet motor runs more efficiently than predecessors
  • Low coil temperature extends service life four times
  • 8 CFM airflow at 0.3 Sone delivers quiet performance

Specifications

No published specifications for this item yet.

Questions about this item

Will the 140 mm frame fit my case's 140 mm mounting holes?

Yes, the fan uses a standard 140 mm square frame with corner screw holes that match typical case mounts.

How do I connect the 4-pin PWM cable so the motherboard controls speed between 200 and 1700 RPM?

Plug the 4-pin connector into a motherboard PWM header; the board then varies voltage on the fourth wire to regulate speed automatically.

When should I clean or replace the fan given the motor runs at lower temperature for extended life?

Clean dust from blades every 6–12 months with compressed air; replace only if bearings become noisy or RPM drops below 200 at full PWM.
