Rectangular metal power distribution module with IEC 309 connector and circuit breaker handle

APC

APC PDM3460IEC309-380 power distribution accessory

SKU CH-30PZ-PWJFT MPN PDM3460IEC309-380

Three-phase 208 V power distribution module with 60 A IEC 309 output and built-in monitoring

  • TypeModule
  • SpecificationsOutput Nominal Output Voltage: 208V 3PH Output Connections:
  • FeaturesMultiple distribution options: Superior design flexibility e
  • Dimensions5.00" x 17.50" x 16.00"
  • Weight9.40 lbs.
  • Delivers 208V three-phase power to critical loads via IEC 309 60A output connection
  • Accepts 200-240VAC input range for flexible deployment across varying utility conditions
  • Built-in monitoring provides real-time power consumption data for connected equipment
  • Safety latch disconnects breaker from AC utility while positive-locking connectors prevent accidental disconnection
  • Compact 5.00 x 17.50 x 16.00 inch module weighs 9.40 lbs for easy relocation

Power Distribution Module

The APC PDM3460IEC309-380 is a three-pole four-wire power distribution module designed for data-centre and industrial environments. It integrates with APC Modular Power Distribution Unit solutions to deliver three-phase power at 208V 3PH. A single IEC 309 60A 3P+PE output connection supplies battery-backed power to connected loads. The unit accepts an input voltage range of 200 to 240VAC at 60 Hz.

Latch and Locking Connectors

A mechanical latch disconnects the internal breaker from AC utility power during service, while positive-locking connectors prevent accidental cable removal. All touch points are isolated to reduce shock risk. Built-in monitoring reports real-time power consumption of attached devices, allowing operators to track load levels without external metering equipment.

Three-Phase 208V Constraint

The module operates only on 208V three-phase supplies within the 200 to 240VAC window at 60 Hz. It cannot be used with single-phase sources, higher voltage three-phase systems or 50 Hz grids. The single 60A output limits total connected load to the rating of that connector, so installations requiring multiple independent circuits need additional modules.

Highlights

  • Delivers 208V three-phase power to critical loads via IEC 309 60A output connection
  • Accepts 200-240VAC input range for flexible deployment across varying utility conditions
  • Built-in monitoring provides real-time power consumption data for connected equipment
  • Safety latch disconnects breaker from AC utility while positive-locking connectors prevent accidental disconnection
  • Compact 5.00 x 17.50 x 16.00 inch module weighs 9.40 lbs for easy relocation

Specifications

BrandAPC
ModelPDM3460IEC309-380
TypeModule
SpecificationsOutput
Nominal Output Voltage: 208V 3PH
Output Connections: 1 x IEC 309 60A (3P+PE) (Battery Backup)
Input
Nominal Input Voltage: 208V 3PH
Input frequency: 60 Hz
Acceptable Input Voltage: 200 - 240VAC
Maximum Line Current: 60A
Approvals: UL; RoHS Compliant
FeaturesMultiple distribution options: Superior design flexibility enables a wide range of customer requirements to be addressed.
System mobility: Power distribution units can easily be relocated to accommodate a changing data center environment.
Dimensions5.00" x 17.50" x 16.00"
Weight9.40 lbs.
Shipping weight4.81 kg
Package size445 × 406 × 127 mm

Questions about this item

What connectors or breakers on the APC PDM3460IEC309-380 will need inspection or replacement over time?

The module uses an IEC 309 60 A connector and internal breakers; these should be checked periodically for wear or heat damage.

What electrical limit is reached first when the APC PDM3460IEC309-380 runs continuously at full load?

The 60 A rating on the IEC 309 output is the primary sustained-current limit.

How much heat or fan noise does the APC PDM3460IEC309-380 produce during all-day operation?

The unit has no internal fans; heat is limited to connector and breaker losses at up to 60 A per phase.
