Silver 2U rack PDU with 16 C13 outlets and NEMA L6-30P plug

APC

APC AP7911B Switched PDU 2U 30A 208V 16x C13

SKU CH-NBDE-06JRG MPN AP7911B

A 2U switched rack PDU delivering 30 A at 208 V through 16 IEC C13 outlets with remote per-outlet control and local current monitoring

  • TypeSwitched
  • Rack Size2U
  • CertificationscUL Listed, CSA, FCC Part 15 Class A, ICES-003, Industry Can
  • ROHSYes
  • Package IncludesRack PDU, Documentation CD, Installation guide, Rack Mountin
  • Input Voltage200V, 208V, 230V
  • Switched control enables remote on/off outlet cycling
  • 16 IEC C13 outlets distribute 208V power to rack gear
  • 30A NEMA L6-30P input with 12.0 ft cord connects to 200-230V supply
  • Local display shows real-time current for load monitoring
  • cUL, UL 60950, FCC Class A certifications confirm safety compliance

Switched PDU for Rack Power Control

The APC AP7911B is a switched power distribution unit built for 2U rack installations. It delivers 208V output through sixteen IEC 60320 C13 outlets fed by a NEMA L6-30P input cord. Network administrators and data-centre operators use it to manage outlet-level power cycling and sequencing across attached servers and networking gear.

Sustained Load Behaviour and Monitoring

The unit operates continuously between 0 and 45 °C at up to 95 % relative humidity, with a local display that reports real-time current draw. Remote management allows thresholds and alarms to be configured so that sustained overloads trigger alerts before a breaker trips. Power-on sequencing delays stagger inrush current across the sixteen outlets during rack start-up.

Pre-Installation Checks

Verify that the facility provides a 200–230 V, 50/60 Hz supply with a compatible NEMA L6-30P receptacle within 12.0 feet of the mounting location. Confirm the rack has 2U of vertical space and that the sixteen C13 outlets match the inlet plugs on the equipment to be powered. Ensure the operating elevation does not exceed 3000 m.

Highlights

  • Switched control enables remote on/off outlet cycling
  • 16 IEC C13 outlets distribute 208V power to rack gear
  • 30A NEMA L6-30P input with 12.0 ft cord connects to 200-230V supply
  • Local display shows real-time current for load monitoring
  • cUL, UL 60950, FCC Class A certifications confirm safety compliance

Specifications

BrandAPC
ModelAP7911B
TypeSwitched
Rack Size2U
CertificationscUL Listed, CSA, FCC Part 15 Class A, ICES-003, Industry Canada, PSE, UL 60950, UL Listed
ROHSYes
Package IncludesRack PDU, Documentation CD, Installation guide, Rack Mounting brackets
Input Voltage200V, 208V, 230V
Input Frequency50/60 Hz
Input Connector(s)NEMA L6-30P
Cord Length12.0 Feet
Output Voltage208V
Output Connector(s)16 x IEC 320 C13 (Battery Backup)
Operating Environment0 - 45 Degree Celcius
Operating Relative Humidity0 - 95%
Operating Elevation0 - 3000 m
Storage Temperature-25 - 65 ºC
Storage Relative Humidity0 - 95%
Storage Elevation0 - 15000 m
FeaturesRemote Management Capabilities
Remote Individual Outlet Control
Power Delays
Alarm Thresholds
Local Current Monitoring Display
Dimensions3.50" x 17.50" x 10.00"
Weight13.90 lbs.
Shipping weight9.53 kg
Package size508 × 508 × 142 mm

Questions about this item

What is the operating temperature range when the PDU runs continuously in a 2U rack slot?

The unit is rated for 0 to 45 degrees Celsius at up to 95 percent relative humidity in normal operation.

What input connection and upstream protection does the AP7911B require to function?

It needs a NEMA L6-30P receptacle fed by a 30-amp 200 to 230-volt single-phase circuit.

Can I monitor and cycle power on each of the 16 C13 outlets from my existing network management console?

Yes, the switched PDU supports remote individual outlet control, power delays and alarm thresholds via its network interface.
